DELPHI FG2187 Fuel Pump Module Assembly

Name: Delphi FG2187 Fuel Pump Module Assembly
SKU: fg2187
Availability: OutOfStock

Out of Stock

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

DELPHI FG2187 Part Description

Fuel Pump Module Assembly

Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
Lower amperage draws less load on vehicle's electrical system
Part is validated, tested and matched to the right vehicle application
Always be sure to check and clean fuel tank to avoid unnecessary returns
Lower failure rates due to its innovative design and durability

Outlet Outside Diameter	0.375 IN
Voltage	12.0 2H
Fuel Type	Gas
Regulator Included	Yes
Terminal Type	Blade
Gasket Or Seal Included	Yes
Terminal Quantity	5
Lock Ring Included	No
Terminal Gender	Male
Strainer Included	Yes
Inlet Type	Strainer
Outlet Type	Quick Connect
Outlet Quantity	3
In Tank or External	In Tank
Resistance Ohms Empty	41.0 82
Resistance Ohms Full	6.0 82
Internal Or External Strainer	External
Average Current Draw	10 68
Pump Type	Electric
Fuel Level Sender Assembly Included	Yes
Item Grade	Standard Replacement
Package Contents	Fuel Pump Module Assembly w/Float Arm, Instruction Sheet
System Pressure	33 psi
Vapor Pressure Sensor	No

Country of Origin (Primary)	JP
Harmonized Tariff Code (Schedule B)	8413309000
Harmonized Tariff Code (HTS)	9026204000
Remanufactured Part	N
Warranty Special	Limited Lifetime
Warranty Special UOM	LF
UPC	00689604295892
VMRS Code	044003258
UNSPSC	25172409
