Centric 320.20030H - Centric GCX Rotor with Full Coating and High Carbon Content
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
Centric GCX Rotor with Full Coating and High Carbon Content
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron Formulation Enhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
Product Attributes
| Weight [cntrc] Lbs | 39.350 |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 5 |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Kgs | 17.860 |
| Disc Mounting [cntrc] | Floating |
| Stud/Lug Hole Diameter | 0.555 IN |
| Stud/Lug Hole Diameter | 14.100 MM |
| Stud/Lug Hole Quantity | 5 |
| Mounting Bolt Hole Circle Diameter | 4.252 IN |
| Mounting Bolt Hole Circle Diameter | 108.000 MM |
| Center Hole Diameter | 70.900 MM |
| Center Hole Diameter | 2.791 IN |
| Bearings Included | No |
| Solid Or Vented Type Rotor | Vented |
| Surface Type | Smooth |
| ABS Tone Ring Included | No |
| Outside Diameter | 14.961 IN |
| Outside Diameter | 380.000 MM |
| Overall Height | 1.890 IN |
| Overall Height | 48.000 MM |
| Hat Finish | Coated |
| Disc Finish | Fully Coated |
| Nominal Thickness | 36.000 MM |
| Nominal Thickness | 1.417 IN |
| Discard Thickness | 34.000 MM |
| Discard Thickness | 1.339 IN |
Additional Information
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 889590386455 |
Part Interchanges
CENTRIC 320.20030H Cross Reference
We have 2 alternatives for the 320.20030H by CENTRIC:
Fits Vehicles
- Jaguar XKR-S (2012, 2014)
- Jaguar XJR575 (2018)
- Jaguar XKR (2010-2012, 2014-2015)
- Jaguar XFR (2010-2015)
- Jaguar XF (2010-2015)
- Jaguar XJ (2010-2018)
- Jaguar XJR (2014-2017)
- Jaguar F-Type (2014-2020)
- Jaguar XFR-S (2013-2015)
