CENTRIC part description

Product Description

Centric GCX Rotor with Full Coating

Application Summary

Ford F-350 Super Duty 2012-2005, F-450 Super Duty 2012-2010

Features & Benefits

  • RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron Formulation Enhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs

Centric; Centric Parts; GxC Brake; GxC Rotor; Brake Rotor

Product Attributes

Discard Thickness 36.400 MM
Nominal Thickness 37.900 MM
Disc Finish Fully Coated
Hat Finish Coated
Overall Height 100.000 MM
Outside Diameter 347.000 MM
Mounting Bolt Hole Quantity 8
ABS Tone Ring Included No
Surface Type Smooth
Solid Or Vented Type Rotor Vented
Bearings Included No
Center Hole Diameter 5.079 IN
Mounting Bolt Hole Circle Diameter 169.800 MM
Mounting Bolt Hole Diameter 16.000 MM
California Proposition 65 Text [basic] WARNING: Cancer and Reproductive Harm
Disc Mounting [cntrc] Behind the Hub
Misc Holes [cntrc] 0
Vane Style [cntrc] Straight
Weight [cntrc] Kgs 16.360
Weight [cntrc] Lbs 36.000

Additional Information

Country of Origin (Primary) CN
Harmonized Tariff Code (HTS) 8708305030
NAFTA Preference Criterion Code B
UPC 00889590393019

Part Interchanges

CENTRIC 320.65110F Cross Reference

We have 3 alternatives for the 320.65110F by CENTRIC:

Fits Vehicles

  • Ford F-450 Super Duty (2010-2012)
  • Ford F-350 Super Duty (2005-2012)
