(888) 312-8812 Login SignupDELPHI TC5552 Ball Joint
Tap to view 6 more
$5999
Limited availability at this price!
In Stock
Get it by Friday, Dec 19
DELPHI TC5552 Part Description
DELPHI TC5552 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Left Lower |
| Material | Steel |
| Color | Black |
| Stud Thread Diameter | 0.71 IN |
| Stud Thread Diameter | 18 MM |
| Castle Nut Included | Yes |
| Grease Fitting Included | No |
| Suspension Grade Type | Standard |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 85.1 MM |
| Type | Threaded |
| Cotter Pin Included | Yes |
| Cotter Pin Hole | Yes |
| Mounting Hardware Included | Yes |
| Mounting Bolt Length | 0.590 IN |
| Mounting Bolt Length | 15.00 MM |
| Washers Included | No |
| Height | 6.100 IN |
| Height | 155.00 MM |
| Nuts Included | No |
| Mounting Hole Quantity | 4 |
| Adjustable | No |
| Greaseable | No |
| Stud Thread Length | 0.83 IN |
| Stud Thread Length | 21 MM |
| Mounting Type | Bolt-In |
| Distance Between Mounting Holes | 49.00 MM |
| Dust Boot Material | Rubber |
| Mounting Bolt Shank Diameter | 0.470 IN |
| Mounting Bolt Shank Diameter | 12.00 MM |
| Mounting Bolts Included | Yes |
| Mounting Bolt Thread Pitch | 1.25 MM |
| Mounting Bolt Thread Length | 0.430 IN |
| Mounting Bolt Thread Length | 11.00 MM |
| Tapered Stud | Yes |
| Stud Thread Pitch | 1.5 MM |
| Length | 245.00 MM |
| Length | 9.650 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | CN |
| UPC | 00689604300473 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
DELPHI TC5552 Part Interchanges
| Brand | Part Number |
|---|---|
| Beck/Arnley | 101-5282 |
| MOOG Chassis Products | K80522 |
| Toyota | 43340-39515, 43340-39575, 4334039595 |
| TRW | JBJ941 |
| N/A | MK80522, BJ74303, GK80522, TXMS86564, BJ74303XL, K500435 |
DELPHI TC5552 Fits Vehicles
- Toyota Sequoia (2004-2007)
- Toyota Tundra (2004-2006)
