DELPHI TC5504 Part Description
Manufacturer
Product Description
Ball Joint
Features & Benefits
- Delphi ball joints manufactured with high quality forgings for increased strength and smooth operation
- Ball joints utilize chloroprene rubber boots which improves durability, preventing premature failure
- Delphi machines to micron tolerances to guarantee durability and smooth joint operation
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC5504 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Left |
| Material | Steel |
| Color | Black |
| Stud Thread Diameter | 14 MM |
| Castle Nut Included | No |
| Grease Fitting Included | No |
| Suspension Grade Type | Standard Replacement |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 76.5 MM |
| Cotter Pin Included | No |
| Cotter Pin Hole | No |
| Mounting Hardware Included | Yes |
| Washers Included | No |
| Height | 4.409 IN |
| Nuts Included | Yes |
| Mounting Hole Quantity | 2 |
| Adjustable | No |
| Greaseable | No |
| Stud Thread Length | 0.886 IN |
| Stud Type | Threaded |
| Mounting Type | Bolt-In |
| Distance Between Mounting Holes | 77.00 MM |
| Dust Boot Material | Rubber |
| Mounting Bolts Included | No |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| Stud Taper Per Foot | 0.1 IN |
| Stud Tapered End 2 Diameter | 0.648 IN |
| Stud Tapered End 2 Diameter | 16.45 MM |
| Stud Tapered End 1 Diameter | 0.719 IN |
| Stud Tapered End 1 Diameter | 18.25 MM |
| Stud Thread Pitch | 1.5 MM |
| Length | 107.00 MM |
| Length | 4.210 IN |
| Stud Thread Diameter | 0.55 IN |
| Height | 111.99 MM |
| Stud Thread Length | 22.5 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708947550 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604301609 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
DELPHI TC5504 Cross References
DELPHI TC5504 Fits Vehicles
- BMW 330xi (2001-2005)
- BMW 325xi (2001-2005)
