DELPHI TC3568 Part Description
Manufacturer
Product Description
Control Arm and Ball Joint Assembly
Features & Benefits
- Delphi control arms undergo 100% crack detection and ultrasonic flaw detection to ensure materials match OE specifications
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Control arms utilize robot welding for consistent performance and quality
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC3568 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Right Lower |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Mounting Type | Press In |
| Ball Joint Stud Type | Threaded |
| Control Arm Construction | Stamped |
| Control Arm Material | Steel |
| Mounting Hardware Included | Yes |
| Mounting Hole Quantity | 4 |
| Adjustable | No |
| Greaseable | No |
| Control Arm Maximum Width | 9.744 IN |
| Control Arm Color | Black |
| Ball Joint Thread Diameter | 18.00 MM |
| Ball Joint Thread Diameter | 0.709 IN |
| Ball Joint Stud Length | 32.00 MM |
| Ball Joint Stud Length | 1.260 IN |
| Control Arm Maximum Length | 485.50 MM |
| Control Arm Maximum Length | 19.114 IN |
| Bushing Material | Rubber |
| Mounting Hole Diameter | 12.20 MM |
| Mounting Hole Diameter | 0.480 IN |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Painted |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Locking Nut Included | Yes |
| Control Arm Maximum Width | 247.50 MM |
| Thread Diameter | 18.00 MM |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Thread Diameter | 0.709 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4016996000 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 4016996050 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604299685 |
| VMRS Code | 016001001 |
| UNSPSC | 25172013 |
DELPHI TC3568 Cross References
| Brand | Part Number |
|---|---|
| Beck/Arnley | 101-7653 |
| DORMAN | CB74364, CB64254PR |
| Dorman | 520-448, 521-394, BJ75085, BJ75085PR, CB64254, CB74364PR |
| MAS Industries | CB64254, CB64254PR, CB74364, CB74364PR, 521-394, BJ75085 |
| MEVOTECH | CMS861220 |
| MOOG | RK621303 |
| MOOG Chassis Products | RK621303 |
| N/A | 1028082, GS86137, CMS86137, 1028088, CMS861220 |
| Toyota | 48068-09100, 48068-60030 |
DELPHI TC3568 Fits Vehicles
- Toyota Land Cruiser (2008-2011, 2013-2021)
- Lexus LX570 (2008-2011, 2013-2021)
