(888) 312-8812 Login SignupDELPHI TA5407 Tie Rod End
Tap to view 5 more
$4599
Limited availability at this price!
In Stock
Get it by Wednesday, Dec 17
DELPHI TA5407 Part Description
DELPHI TA5407 Specifications
Product Attributes
| Position(s) | Inner |
| Item Grade | Standard Replacement |
| Length | 380.50 MM |
| Color | Black |
| End 1 Gender | Male |
| End 2 Gender | Female |
| Pre-Greased | Yes |
| Grease Fitting Included | Yes |
| Dust Boot Included | Yes |
| Width | 36.1 MM |
| Type | Straight |
| Mounting Hardware Included | Yes |
| End 2 Thread Diameter | 0.630 IN |
| End 2 Thread Diameter | 16.00 MM |
| Height | 36.10 MM |
| Housing Material | Steel |
| Adjustable | No |
| Greaseable | Yes |
| Weight | 1.32 lb |
| Cone Outside Diameter | 0.591 IN |
| Cone Outside Diameter | 15.00 MM |
| Bearing Material | Plastic |
| End 1 Thread Direction | Clockwise (Right) |
| End 2 Thread Direction | Clockwise (Right) |
| Grade | Premium |
| Stud Type | Threaded |
| End 2 Thread Pitch | 2 MM |
| End 1 Thread Pitch | 1.5 MM |
| Length - Stud Center to End | 12.343 IN |
| Length - Stud Center to End | 313.50 MM |
| Dust Boot Material | Rubber |
| Tie Rod Material | Steel |
| End 1 Thread Diameter | 0.551 IN |
| End 1 Thread Diameter | 14.00 MM |
| Shank Length | 15.00 MM |
| Stud Length | 15.00 MM |
| Grade Type | Standard |
| Boot Color | Black |
| Shank Length | 0.591 IN |
| Stud Length | 0.591 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708998180 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708998175 |
| Country of Origin (Primary) | CN |
| UPC | 00689604300596 |
| VMRS Code | 015004070 |
| UNSPSC | 25174205 |
DELPHI TA5407 Part Interchanges
| Brand | Part Number |
|---|---|
| MOOG Chassis Products | ES80277 |
| General Motors | 12479168, 19149613, 19257595 |
| MAS Industries | 534-954 |
| TRW | JTE1296 |
| N/A | MES80277, TI92070, 534-954, GES80277 |
DELPHI TA5407 Fits Vehicles
- GMC Savana 3500 (2003-2022)
- GMC Savana 2500 (2003-2022)
- Chevrolet Express 3500 (2003-2022)
- Chevrolet Express 2500 (2003-2022)
