DELPHI TA5404 Part Description
Manufacturer
Product Description
Tie Rod End
Features & Benefits
- Delphi includes the necessary accessories for a complete job
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Delphi tie rods are fatigue tested to avoid failure
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TA5404 Specifications
Product Attributes
| Position(s) | Inner |
| Item Grade | Standard Replacement |
| Length | 304.50 MM |
| Color | Black |
| End 1 Gender | Male |
| End 2 Gender | Male |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Dust Boot Included | No |
| Width | 39.1 MM |
| Type | Straight |
| Mounting Hardware Included | Yes |
| End 2 Thread Diameter | 0.630 IN |
| End 2 Thread Diameter | 16.00 MM |
| Height | 39.10 MM |
| Housing Material | Steel |
| Adjustable | No |
| Greaseable | No |
| Weight | 1.23 lb |
| Cone Outside Diameter | 0.669 IN |
| Cone Outside Diameter | 17.00 MM |
| Bearing Material | Plastic |
| End 1 Thread Direction | Clockwise (Right) |
| End 2 Thread Direction | Clockwise (Right) |
| Grade | Premium |
| Stud Type | Threaded |
| End 2 Thread Pitch | 1 MM |
| End 1 Thread Pitch | 1.5 MM |
| Length - Stud Center to End | 10.472 IN |
| Length - Stud Center to End | 266.00 MM |
| Tie Rod Material | Steel |
| End 1 Thread Diameter | 0.551 IN |
| End 1 Thread Diameter | 14.00 MM |
| Shank Length | 17.00 MM |
| Stud Length | 17.00 MM |
| Grade Type | Standard Replacement |
| Boot Color | Black |
| Shank Length | 0.669 IN |
| Stud Length | 0.669 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708998175 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708998180 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604300497 |
| VMRS Code | 015004070 |
| UNSPSC | 25174205 |
DELPHI TA5404 Cross References
| Brand | Part Number |
|---|---|
| Beck/Arnley | 101-5506 |
| DORMAN | TI61140, TI61140XL |
| Datsun/Nissan | 48521-AR025 |
| MEVOTECH | MS30710 |
| MOOG Chassis Products | EV800339 |
| N/A | 48521AR000, 48521-AR085, MS30710, 61242136, TI61140, JAR370 |
| TRW | JAR744 |
DELPHI TA5404 Fits Vehicles
- INFINITI Q45 (2002-2004)
