DELPHI TA5164 - Tie Rod End
$5649
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DELPHI part description
California Proposition 65 Warning
California Proposition 65 Warning
WARNING: This product can expose you to chemicals including Carbon black, which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov. (Read more)
Product Description
Tie Rod End
Product Attributes
| Position(s) | Right Inner, Right Outer. For the position specific to your vehicle, refer to the Applications. |
| Item Grade | Standard Replacement |
| Length | 469.9 MM |
| Color | Black |
| End 1 Gender | Male |
| End 2 Gender | Male |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Dust Boot Included | Yes |
| Width | 65.0 MM |
| Type | Bent |
| Mounting Hardware Included | Yes |
| Height | 125.0 MM |
| Housing Material | Steel |
| Adjustable | No |
| Greasable | No |
| Weight | 3.63 lb |
| 662 | 0.63 IN |
| Cone Outside Diameter | 15.9 MM |
| Bearing Material | Polyoxymethilen (POM) |
| End 1 Thread Direction | Clockwise (Right) |
| End 2 Thread Direction | Counterclockwise (Left) |
| Grade | Standard |
| Stud Type | Threaded |
| End 1 Thread Pitch | 1.5 MM |
| Length Stud Center to End | 3.11 IN |
| Length Stud Center to End | 79.0 MM |
| Dust Boot Material | Choloroprene Rubber (CR) |
| Tie Rod Material | Steel |
| End 1 Thread Diameter | 0.551 IN |
| End 1 Thread Diameter | 14.0 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708998175 |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708998180 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604297322 |
| VMRS Code | 015004070 |
| UNSPSC | 25174205 |
Part Interchanges
Fits Vehicles
- Ford F-350 Super Duty (2011-2020)
- Ford F-250 Super Duty (2011-2020)
