(888) 312-8812 Login SignupDELPHI AF10323 Mass Air Flow Sensor
$16099
Limited availability at this price!
1 Day Lead Time
Get it by Thursday, Sep 3
DELPHI AF10323 Part Description
Manufacturer
Product Description
Mass Air Flow Sensor
Features & Benefits
- Delphi mass air flow sensors are the global benchmark for accuracy and signal noise
- Delphi mass air flow sensors feature high quality sensing elements for outstanding performance over a wide range of ambient temperatures
- Delphi is a manufacturer of OE mass air flow sensors since their first use over 30 years ago
- All parts are calibrated and tested to match the OE part
- Probe solution offered wherever possible to reduce repair time by eliminating the need to replace the flow tube
- Delphi OE technology validated to match the vehicle applications
DELPHI AF10323 Specifications
Product Attributes
| Item Grade | Premium |
| Package Contents | Mass Air Flow Sensor - Complete Assembly |
| Color | Black |
| Housing Included | Yes |
| Inlet Connection Diameter | 2.43 IN |
| Inlet Connection Diameter | 61.6 MM |
| Outlet Connection Diameter | 3.07 IN |
| Outlet Connection Diameter | 78 MM |
| Terminal Type | Blade |
| Mounting Hardware Included | No |
| Universal Or Specific Fit | Specific |
| Grade Type | Standard Replacement |
| Connector Quantity | 1 |
| Connector Shape | Rectangle |
| Mounting Hole Quantity | 4 |
| Housing Material | Plastic |
| Terminal Quantity | 7 |
| Connector Gender | Female |
| Terminal Gender | Male |
| Wiring Harness Included | No |
| Mounting Type | Bolt-On |
| Mounting Bracket Included | No |
| Sensor Casing Length | 160 MM |
| Sensor Casing Width | 132 MM |
| Voltage | 12.0 2H |
| Gasket Or Seal Included | Yes |
| Bolt Hole Center To Bolt Hole Center | 62.00 MM |
| Mounting Hole Diameter | 6.5 MM |
| Seal Outside Diameter | 117 mm |
| Seal Quantity | 1 |
| Sensor Casing Length | 6.2 IN |
| Sensor Casing Width | 5.1 IN |
| Bolt Hole Center To Bolt Hole Center | 2.40 IN |
| Mounting Hole Diameter | 0.2 IN |
| Seal Outside Diameter | 4.6 IN |
| Intake Air Temperature (IAT) Included | Yes |
Additional Information
| Harmonized Tariff Code (HTS) | 9026802000 |
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9026800000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| UPC | 00689604300299 |
| VMRS Code | 045021019 |
| UNSPSC | 41111931 |
DELPHI AF10323 Cross References
| Brand | Part Number |
|---|---|
| BWD | 20428M |
| Beck/Arnley | 158-0838 |
| Bosch | 63031 |
| CARDONE Reman | 74-60006 |
| Carquest | MQ7264 |
| Chrysler | MD183609, MD183618, MD357338 |
| Mitsubishi | MD183609, MD183618, MD357338 |
| N/A | MQ7235, 245-1152 |
| NAPA Reman Computers | XTP460006 |
| NGK SPARK PLUGS | MG0087 |
| NTK | MG0087 |
| Standard Motor Products | MF0428 |
| WAI | MAF20109T |
| Wells | SU4136, SU4138 |
DELPHI AF10323 Fits Vehicles
- Mitsubishi Eclipse (1995-1999)
- Mitsubishi Galant (1994-1998)
- Mitsubishi Expo (1993-1995)
- Mitsubishi Expo LRV (1993-1994)
- Mitsubishi Montero (1992-2000)
- Mitsubishi Diamante (1992-2004)
- Mitsubishi Mighty Max (1991-1994)
- Mitsubishi 3000GT (1991-1999)
- Plymouth Colt (1993-1994)
- Eagle Talon (1995-1998)
- Eagle Summit (1993-1996)
- Dodge Stealth (1992-1996)
- Dodge Ram 50 (1991)
