DELPHI TC5516 - Suspension Stabilizer Bar Link
$2999
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DELPHI part description
California Proposition 65 Warning
California Proposition 65 Warning
WARNING: This product can expose you to chemicals including Ethylene Thiourea, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov. (Read more)
Product Description
Suspension Stabilizer Bar Link
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Left |
| Material | Ball Pin -Steel, Outer Sleeve - Steel |
| Bushing Outside Diameter | 1.476 IN |
| Bushing Outside Diameter | 37.5 MM |
| Bushing Color | Black |
| Length | 5.079 IN |
| Length | 129.0 MM |
| End 2 Type | Male - M14 x 1.5 |
| Bushings Included | Yes |
| Dust Boot Included | Yes |
| Sleeve Inside Diameter | 0.563 IN |
| Sleeve Inside Diameter | 14.3 MM |
| Sleeve Length | 1.496 IN |
| Sleeve Length | 38.0 MM |
| Width | 44.0 MM |
| Width | 1.732 IN |
| Washers Included | Yes |
| Height | 3.504 IN |
| Height | 89.0 MM |
| Grade Type | Performance |
| Bolts Included | No |
| Housing Material | Steel |
| Greasable | No |
| Weight | 1.08 lb |
| Bearing Material | Polyoxymethilen (POM) |
| Bushing Material | Rubber |
| 839 | 6.0mm |
| Distance Between Mounting Holes | 85.0 MM |
| Locking Nuts Included | Yes |
| Bushing Inside Diameter | 0.945 IN |
| Bushing Inside Diameter | 24.0 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604300244 |
| VMRS Code | 016004006 |
| UNSPSC | 25172001 |
Part Interchanges
Fits Vehicles
- Toyota Sequoia (2008-2021)
- Toyota Tundra (2007-2021)
