FLEETGUARD HF7950 - Hydraulic Filter Spin-On
- Part Number
- HF7950
- Manufacturer
- FLEETGUARD
- Description
-
Hydraulic Filter Spin-On
details
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
FLEETGUARD part description
California Proposition 65 Warning
Attributes | |
---|---|
Largest Outside Diameter | 135.74 mm (5.344 in) |
Seam Outside Diameter | 136.86 mm (5.388 in) |
Gasket Outside Diameter | 109.22 mm (4.3 in) |
GASKET INSIDE DIAMETER | 99.82 mm (3.93 in) |
Thread Size | M42 X 2-6H INT |
Standpipe | NO |
ADBV | null |
BPV Setting | 28 kPa (4.06 PSI) |
TWA MICRON @ BETA=2 | 2 micron (2 micron) |
TWA MICRON @ BETA=20 | 8 micron (8 micron) |
TWA MICRON @ BETA=200 | 13 micron (13 micron) |
TWA MICRON @ BETA=75 | 12 micron (12 micron) |
Additional Information | |
3845105 | Gasket |
FLEETGUARD HF7950 Cross Reference
We have 2 alternatives for the HF7950 by FLEETGUARD:
Since 1987, Fleetguard® has been one of the world's leaders in filtration solutions for both on- and off-highway applications. Whether it's air, fuel, oil, or hydraulic filtration, Fleetguard filters provide superior protection against contaminants for engines and sensitive equipment in the agriculture, construction, commercial vehicle, marine, mining, and power generation industries. Each filter is fitted with high-quality filter media for longer service life as well as a more compact design to accommodate shrinking engine compartments found in modern vehicles. All products also undergo extensive performance tests and strict quality control procedures to ensure durability and consistent performance, even in the most demanding operating conditions.
