DORMAN part description

Product Description

Air Tank Secondary

Application Summary

International 2007-02

Features & Benefits

  • Direct replacement - this air reservoir features the same port configuration and physical dimensions as the original tank
  • Quality construction - this tank is made with precise port locations and finished in a corrosion-resistant coating inside and outside
  • Validation tested - has been salt spray chamber tested internally and externally to meet or exceed industry standard for corrosion resistance
  • Excellent value - original equipment quality at a lower cost

Air, Brake, Reservoir, Reservoirs, Brakes

Product Attributes

Material Carbon Steel
Diameter 8.5 IN
Length 55 IN
Color Black
Mounting Hardware Included No
Material Thickness 0.13 IN
Mounting Hole Quantity 0
Maximum Working Pressure 150 PSI
Mounting Type Strap On
Package Contents 1 Air Tank
Port Quantity 5
Port Thread Diameter M22; M27; 1/4 in; 1/2 in; 1/4 in
Port Thread Pitch 1.5 mm; 2 mm;
Port Threads Per Inch NPT; NPT; NPT
Tank Chamber Quantity 1
Threaded Mounting Bracket Included No
Valve Included No
Volume 50 L

Additional Information

Country of Origin (Primary) IN
Harmonized Tariff Code (Schedule B) 7311000000
UPC 00889245201263
VMRS Code 013010004
UNSPSC 20142905

Part Interchanges

DORMAN 924-5808 Cross Reference

We have 1 alternatives for the 924-5808 by DORMAN:

Fits Vehicles

  • International 9900ix (2002-2007)
  • International 9900i (2002-2007)
  • International 9900ix SFA (2002-2003)
  • International 9200i SBA (2002-2007)
  • International 9900i SFA (2002-2003)
  • International 9400i SBA (2002-2007)
  • International 9100i SBA (2002-2003)
