(888) 312-8812 Login SignupWABCO 4750103050 Air Brake Limiting Valve - Pressure Regulator
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
WABCO 4750103050 Part Description
WABCO 4750103050 Specifications
Product Attributes
| Calculated Volume (dm³) | 0.68255 |
| Size | 146 x 85 x 55 |
| Weight | 0.81571 |
| Mounting | 2x Ø 8.6 mm |
| Temperature Range | -40°C to +80°C |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M22 x 1.5 |
| Port threads | M22 x 1.5 |
| Exhaust | Ø 4 mm |
| Delivered Pressure | 6.0 at p1 = 7.5 bar |
| Max. operating pressure | 20.0 bar |
| Range Of Adjustment | 5.8 to 10.8 bar |
| Distance between bolts | 56 mm |
WABCO 4750103050 Manufacturer Information
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
