LUK LFW450 - Clutch Flywheel LuK LFW450
$14999
In stock
limited availability at this price!
. Learn more
LUK part description
California Proposition 65 Warning
California Proposition 65 Warning
Product Description
LuK Rigid Flywheel
Application Summary
Volkswagen Beetle 2012-2013 (L5, 2.5L), Volkswagen Golf 2012-2013 (L5, 2.5L), Volkswagen Jetta 2011-2014 (L5, 2.5L), Volkswagen Passat 2012-2014 (L5, 2.5L)
Product Attributes
| Flange Thickness | 0.315 inch |
| Flange Thickness | 8 MM |
| Ring Gear Thickness | 0.394 inch |
| Ring Gear Thickness | 10 mm |
| Flywheel friction surface outer diameter | 8.957 inch |
| Flywheel friction surface outer diameter | 227.5 mm |
| Flywheel Thickness [mm] | 1.854 inch |
| Flywheel Thickness [mm] | 47.1 mm |
| I.D. for Pilot | 1.772 inch |
| I.D. for Pilot | 45 mm |
| Ring Gear Number | L-01180-0913-00 |
| Centering diameter / dowel hole | 10.157 inch |
| Centering diameter / dowel hole | 258 mm |
| Crank Hole Dia. | 0.425 inch |
| Crank Hole Dia. | 10.8 mm |
| Bolt hole PCD clutch pres.plte | 10.157 inch |
| Bolt hole PCD clutch pres.plte | 258 mm |
| Flywheel Cup Depth or Step Height | -0.591 inch |
| Flywheel Cup Depth or Step Height | -15 mm |
| Flywheel Friction Surface Inner diameter | 6.154 inch |
| Flywheel Friction Surface Inner diameter | 156.3 mm |
| Dowel hole diameter | 0.236 inch |
| Dowel hole diameter | 6 mm |
| Overall Casting O.D. | 11.063 inch |
| Overall Casting O.D. | 281 mm |
| Ring Gear Major Dia. | 11.075 inch |
| Ring Gear Major Dia. | 281.3 mm |
| Crank To Friction Surface | 0.626 inch |
| Crank To Friction Surface | 15.9 mm |
| Bolt hole PCD crankshaft | 2.598 inch |
| Bolt hole PCD crankshaft | 66 mm |
| Bolt Hole Pattern | 2 |
| Number of teeth, starter ring gear | 132 |
| Ring Gear Mounting O.D. | 9.484 inch |
| Ring Gear Mounting O.D. | 240.9 mm |
Additional Information
| Remanufactured Part | N |
| Warranty Special | 12 months or 12,000 miles - whichever comes first |
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (HTS) | 8483508080 |
| Stock Status | S |
| UPC | 670774369292 |
Part Interchanges
Fits Vehicles
- Volkswagen Passat (2012-2014)
- Volkswagen Beetle (2012-2013)
- Volkswagen Golf (2012-2013)
- Volkswagen Jetta (2011-2014)
LuK® is a worldwide leader in manufacturing clutches, power steering pumps, dual-mass flywheels, and self-adjusting clutch and engine components for various vehicle applications. It was founded by brothers George and Wilhelm Schaeffler in 1965. Initially, it was established as a manufacturer of diaphragm spring clutches with a release system. But when it was acquired by Schaeffler Group, a globally known supplier of chassis, engine, and transmission components for automotive and industrial applications, the company has grown immensely. Currently, LuK has research and development centers, offices, and manufacturing plants around the world. It remains steadfast to its commitment to providing only the highest quality clutches and other transmission, steering, suspension, and engine components.
