(888) 312-8812 Login SignupDELPHI TC2424 Ball Joint
Tap to view 5 more
$2499
Limited availability at this price!
1 Day Lead Time
Get it by Tuesday, Jul 14
DELPHI TC2424 Part Description
Manufacturer
Product Description
Ball Joint
Features & Benefits
- Delphi ball joints manufactured with high quality forgings for increased strength and smooth operation
- Ball joints utilize chloroprene rubber boots which improves durability, preventing premature failure
- Delphi machines to micron tolerances to guarantee durability and smooth joint operation
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC2424 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Lower |
| Material | Steel |
| Maximum Outside Diameter | 2.354 IN |
| Maximum Outside Diameter | 59.80 MM |
| Color | Gray |
| Stud Thread Diameter | 20 MM |
| Castle Nut Included | No |
| Grease Fitting Included | No |
| Suspension Grade Type | Standard Replacement |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 59.8 MM |
| Cotter Pin Included | No |
| Cotter Pin Hole | No |
| Mounting Hardware Included | Yes |
| Washers Included | Yes |
| Height | 4.173 IN |
| Height | 104.00 MM |
| Nuts Included | Yes |
| Adjustable | No |
| Greaseable | No |
| Stud Thread Length | 1.004 IN |
| Stud Type | Threaded |
| Mounting Type | Press-In |
| Dust Boot Material | Rubber |
| Mounting Bolts Included | No |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| Stud Taper Per Foot | 0.167 IN |
| Stud Tapered End 2 Diameter | 0.858 IN |
| Stud Tapered End 2 Diameter | 21.8 MM |
| Stud Tapered End 1 Diameter | 1.059 IN |
| Stud Tapered End 1 Diameter | 26.9 MM |
| Stud Thread Pitch | 1.5 MM |
| Stud Thread Diameter | 0.79 IN |
| Stud Thread Length | 25.5 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604301722 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
DELPHI TC2424 Cross References
| Brand | Part Number |
|---|---|
| CORTECO | 49395301 |
| DORMAN | BJ81475, BJ81475XL |
| MEVOTECH | MS25516, TXMS25516 |
| MEYLE | 016 010 0015 |
| MOOG | K500113, K500113T005 |
| Mercedes-Benz | 2E0 407 152M, 906 330 40 07, 906 330 41 07 |
| N/A | K500113, MS25516, BJ81475, 537-129, TXMS25516, 2E0 407 151 M, 2E0 407 152M, 906 330 46 07, 906 330 47 07, A 906 330 40 07, A906 330 41 07, A 906 330 46 07, A 906 330 47 07 |
| QUICK STEER | K500113 |
| TRW | JBJ112, JBJ804 |
DELPHI TC2424 Fits Vehicles
- Freightliner Sprinter 2500 (2007-2020)
- Freightliner Sprinter 3500 (2007-2020)
- Mercedes-Benz Sprinter 1500 (2020-2021)
- Mercedes-Benz Sprinter 3500 (2010-2021)
- Mercedes-Benz Sprinter 2500 (2010-2021)
- Dodge Sprinter 2500 (2007-2009)
- Dodge Sprinter 3500 (2007-2009)
