Name: ACDelco 18A2943AC Coated Rear Disc Brake Rotor
SKU: 18a2943ac
Price: 58.49 USD
Availability: InStock

ACDELCO part description

Product Description

Rear Brake Rotor

Product Attributes

Discard Thickness	0.335 IN
Nominal Thickness	0.394 IN
Center Bore Diameter (in)	2.4in
Height (in)	2.5 in
Width (in)	2.8 in
Bolt Circle Diameter (in)	4.5 in
Bolt Hole Quantity	5
Mounting Bolt Hole Diameter	14.5 MM
Nominal Thickness	10 MM
Outside Diameter	309.05 MM
Weight	12.8 lb
Length (In)	13.5 IN
Center Bore Diameter (mm)	61mm
Height (mm)	63.5 mm
Bolt Circle Diameter (mm)	114.3 mm
Overall Height	2.45 IN
Discard Thickness	8.5 MM
Product Description	ACDelco Advantage Coated Disc Brake Rotors provide reliable vehicle braking power. Their robotic-applied, baked-on coating helps prevent brake pulsation, helps prevent the rotor from seizing to the hub, and provides superior rust prevention against harsh environmental elements such as rain, snow, and corrosive road sprays. They feature a non-directional ground finish that helps to extend brake pad life and minimizes thickness variation. They are also ready to be installed right out of the box, with no machining required. These dependable aftermarket Advantage Coated Disc Brake Rotors offer quality at an economical price. ⚠<b> WARNING:</b> Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Material	Cast Iron
FAQ - Question 1	Does ACDelco offer other grades of brake rotors?
Construction	Full Cast
Features & Benefits - Bullet 1	Manufactured with multiple alloys for improved heat dissipation and performance
Features & Benefits - Bullet 2	Mill-balanced for proper rotor function; no extra weights needed
Slotted	No
Programming Required	No
Disc Finish	Non Directional
Hat Finish	Plain
Features & Benefits - Bullet 3	Quality validated for proper metallurgy and correct brake plate thickness
Grade Type	Regular
Features & Benefits - Bullet 4	Rounded radius for added strength
Surface Type	Smooth
Solid Or Vented Type Rotor	Solid
Signs of Wear & Troubleshooting - Section 1 - Bullet 4	Vehicle pulls to the left or right when brakes are applied.
Signs of Wear & Troubleshooting - Section 1 - Bullet 5	Visible ridges or deep grooves on the rotor surface.
Rust Resistant Coating	Yes
FAQ - Answer 1	Yes, ACDelco also offers GM OE brake rotors and Professional brake rotors.
Inside Diameter	9.079 IN
Inside Diameter	230.6 MM
Mounting Bolt Hole Circle Diameter	4.5 IN
Mounting Bolt Hole Circle Diameter	114.3 MM
Mounting Bolt Hole Diameter	0.57 IN
Mounting Bolt Hole Quantity	5
Outside Diameter	12.167 IN
Center Hole Diameter	62 MM
Center Hole Diameter	2.44 IN
Directional or Non-Directional Brake Surface	Non-Directional
Stud/Lug Hole Quantity	5
Conventional Or Drum-In-Hat Type Rotor	Drum-In-Hat
Overall Height	62.25 MM
ABS Tone Ring Included	No

Additional Information

Warranty Special	12 Months/Unlimited Miles Warranty (Parts Only). Please see ACDelco.com for more details\|24 Months/40,000 Kilometers (Parts Only). Please see ACDelcocanada.com for more details
Harmonized Tariff Code (HTS)	8708305030
Country of Origin (Primary)	CN
Warranty Special UOM	TX
UPC	00808709342205

Fits Vehicles

Toyota Highlander (2014-2019)
Lexus RX450h (2010-2015)
Toyota Sienna (2011-2020)
Lexus RX350 (2010-2015)
