DELPHI TC5402 Part Description
Manufacturer
Product Description
Ball Joint
Features & Benefits
- Delphi ball joints manufactured with high quality forgings for increased strength and smooth operation
- Ball joints utilize chloroprene rubber boots which improves durability, preventing premature failure
- Delphi machines to micron tolerances to guarantee durability and smooth joint operation
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC5402 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Upper |
| Material | Steel |
| Maximum Outside Diameter | 2.008 IN |
| Maximum Outside Diameter | 51.00 MM |
| Color | Gray |
| Stud Thread Diameter | 0.438 IN |
| Castle Nut Included | Yes |
| Grease Fitting Included | Yes |
| Suspension Grade Type | Standard Replacement |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 51 MM |
| Cotter Pin Included | Yes |
| Cotter Pin Hole | Yes |
| Mounting Hardware Included | Yes |
| Washers Included | No |
| Height | 4.134 IN |
| Nuts Included | Yes |
| Adjustable | No |
| Greaseable | Yes |
| Stud Thread Length | 0.748 IN |
| Stud Type | Threaded |
| Mounting Type | Press-In |
| Dust Boot Material | Rubber |
| Mounting Bolts Included | No |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| Stud Taper Per Foot | 0.125 IN |
| Stud Tapered End 2 Diameter | 0.502 IN |
| Stud Tapered End 2 Diameter | 12.75 MM |
| Stud Tapered End 1 Diameter | 0.591 IN |
| Stud Tapered End 1 Diameter | 15 MM |
| Stud Threads Per Inch | 20 |
| Length | 105.00 MM |
| Length | 4.130 IN |
| Stud Thread Diameter | 11.13 MM |
| Height | 105.00 MM |
| Stud Thread Length | 19 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| UPC | 00689604290460 |
| VMRS Code | 016001014 |
| UNSPSC | 25174203 |
DELPHI TC5402 Cross References
DELPHI TC5402 Fits Vehicles
- Plymouth Valiant (1960-1972)
- Plymouth Scamp (1971-1972)
- Plymouth Duster (1970-1972)
- Plymouth Barracuda (1964-1969)
- Dodge Lancer (1961-1962)
- Dodge Dart (1963-1972)
