DELPHI TC5288 Part Description
DELPHI TC5288 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Lower |
| Material | Ball Material - Alloy Steel SAE 5140, Housing Material - Carbon Steel SAE 1040 |
| Color | Gray |
| Stud Thread Diameter | 0.47 IN |
| Stud Thread Diameter | 12 MM |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 55.5 MM |
| Cotter Pin Hole | No |
| Mounting Hardware Included | Yes |
| Washers Included | No |
| Height | 3.728 IN |
| Height | 94.70 MM |
| Nuts Included | Yes |
| Mounting Hole Quantity | 0 |
| Adjustable | No |
| Stud Thread Length | 0.945 IN |
| Stud Thread Length | 24 MM |
| Mounting Type | Press-In |
| Dust Boot Material | Rubber |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| Stud Tapered End 2 Diameter | 0.748 IN |
| Stud Tapered End 2 Diameter | 19 MM |
| Stud Tapered End 1 Diameter | 0.61 IN |
| Stud Tapered End 1 Diameter | 15.5 MM |
| Stud Thread Pitch | 1.5 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| UPC | 00689604287606 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
DELPHI TC5288 Part Interchanges
| Brand | Part Number |
|---|---|
| MOOG Chassis Products | K500082 |
| Chrysler | 4766911AD |
| TRW | JBJ168 |
| N/A | 4721492AB, GS25507, BJ81325, 535-626, TXMS25507, MS25507, K500362 |
DELPHI TC5288 Fits Vehicles
- Ram C/V (2012-2015)
- Volkswagen Routan (2009-2014)
- Dodge Grand Caravan (2008-2020)
- Chrysler Town & Country (2008-2016)
