(888) 312-8812 Login SignupDELPHI TC3144 Ball Joint
Tap to view 8 more
$5549
Limited availability at this price!
In Stock
Get it by Friday, Dec 19
DELPHI TC3144 Part Description
DELPHI TC3144 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Upper |
| Material | Ball Material - Alloy Steel SAE 5140, Housing Material - Carbon Steel SAE 1040 |
| Color | Gray |
| Stud Thread Diameter | 16 MM |
| Grease Fitting Included | No |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 64.5 MM |
| Cotter Pin Hole | No |
| Mounting Hardware Included | Yes |
| Washers Included | No |
| Height | 4.783 IN |
| Height | 121.50 MM |
| Nuts Included | Yes |
| Mounting Hole Quantity | 0 |
| Adjustable | No |
| Greaseable | No |
| Stud Thread Length | 0.846 IN |
| Stud Thread Length | 21.5 MM |
| Mounting Type | Press-In |
| Dust Boot Material | Rubber |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| Stud Tapered End 2 Diameter | 0.846 IN |
| Stud Tapered End 2 Diameter | 21.5 MM |
| Stud Tapered End 1 Diameter | 0.709 IN |
| Stud Tapered End 1 Diameter | 18 MM |
| Stud Thread Pitch | 2 MM |
| Stud Thread Diameter | 0.63 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604287699 |
| VMRS Code | 016001014 |
| UNSPSC | 25174203 |
DELPHI TC3144 Part Interchanges
| Brand | Part Number |
|---|---|
| MOOG Chassis Products | K80604 |
| Chrysler | 5135650AB |
| MAS Industries | 531-429 |
| TRW | JBJ1006 |
| N/A | GK80604, 531-429, TSMS25558, MK80604, BJ96046 |
DELPHI TC3144 Fits Vehicles
- Jeep Commander (2006-2007)
- Jeep Grand Cherokee (2005-2010)
