Position(s)	Front Upper
Item Grade	Standard Replacement
Material	Steel
Color	Gray
Stud Thread Diameter	0.563 IN
Castle Nut Included	Yes
Grease Fitting Included	No
Suspension Grade Type	Standard
Bushings Included	No
Dust Boot Included	Yes
Ball Joint Assembly	Yes
Width	80 MM
Cotter Pin Included	Yes
Cotter Pin Hole	Yes
Mounting Hardware Included	Yes
Mounting Bolt Length	0.984 IN
Mounting Bolt Length	25.00 MM
Washers Included	No
Height	3.543 IN
Nuts Included	Yes
Mounting Hole Quantity	3
Adjustable	No
Greaseable	No
Stud Thread Length	1.024 IN
Wrench Size	13mm
Stud Type	Threaded
Mounting Type	Bolt-In
Dust Boot Material	Rubber
Mounting Bolt Shank Diameter	0.313 IN
Mounting Bolt Head Diameter	0.571 IN
Mounting Bolt Head Diameter	14.50 MM
Mounting Bolts Included	Yes
Mounting Bolt Threads Per Inch	24
Mounting Bolt Thread Length	23.00 MM
Mount Plate Included	No
Tapered Stud	Yes
Stud Taper Per Foot	0.125 IN
Stud Tapered End 2 Diameter	0.602 IN
Stud Tapered End 2 Diameter	15.3 MM
Stud Tapered End 1 Diameter	0.685 IN
Stud Tapered End 1 Diameter	17.4 MM
Stud Threads Per Inch	18
Length	88.00 MM
Length	3.460 IN
Stud Thread Diameter	14.3 MM
Height	89.99 MM
Stud Thread Length	26.01 MM
Mounting Bolt Shank Diameter	7.95 MM
Mounting Bolt Thread Length	0.910 IN

Harmonized Tariff Code (Schedule B)	8708807000
Harmonized Tariff Code (HTS)	8708806590
Warranty Special	Limited Lifetime
Warranty Special UOM	LF
Country of Origin (Primary)	TR
UPC	00689604290361
VMRS Code	016001014
UNSPSC	25174203

Delphi TC2579 - Ball Joint

Ball Joint
