(888) 312-8812 Login SignupDELPHI TA5316 Tie Rod End
Tap to view 5 more
$3199
Limited availability at this price!
In Stock
Get it by Friday, Feb 20
DELPHI TA5316 Part Description
Manufacturer
Product Description
Tie Rod End
Features & Benefits
- Delphi includes the necessary accessories for a complete job
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Delphi tie rods are fatigue tested to avoid failure
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TA5316 Specifications
Product Attributes
| Position(s) | At Pitman Arm, Left Inner, Left Outer, Left Outer (Steering Arm To Steering Arm), Outer, Right (At Connecting Rod - Bell Crank To Connectin, Right Outer (Steering Arm To Steering Arm). For the position specific to your vehicle, refer to the Applications. |
| Item Grade | Standard Replacement |
| Length | 104.00 MM |
| Color | Black |
| End 1 Gender | Male |
| End 2 Gender | Male |
| Pre-Greased | Yes |
| Grease Fitting Included | Yes |
| Dust Boot Included | Yes |
| Width | 41 MM |
| Type | Straight |
| Mounting Hardware Included | Yes |
| End 2 Thread Diameter | 0.687 IN |
| End 2 Thread Diameter | 17.46 MM |
| Height | 79.80 MM |
| Housing Material | Steel |
| Tube Diameter | 0.688 IN |
| Tube Diameter | 17.46 MM |
| Adjustable | No |
| Greaseable | Yes |
| Weight | 0.79 lb |
| Cone Outside Diameter | 16.00 MM |
| Bearing Material | Plastic |
| End 2 Thread Direction | Counterclockwise (Left) |
| Stud Type | Threaded |
| Length - Stud Center to End | 3.268 IN |
| Length - Stud Center to End | 83.00 MM |
| Dust Boot Material | Rubber |
| Tie Rod Material | Steel |
| End 2 Threads Per Inch | 18 |
| End 1 Threads Per Inch | 20 |
| End 1 Thread Diameter | 0.500 IN |
| End 1 Thread Diameter | 12.70 MM |
| Shank Length | 16.00 MM |
| Stud Length | 16.00 MM |
| Grade Type | Standard Replacement |
| Grade | Premium |
| Shank Length | 0.630 IN |
| Stud Length | 0.630 IN |
| Cone Outside Diameter | 0.630 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708998175 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708998180 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604290293 |
| VMRS Code | 015004045 |
| UNSPSC | 25174205 |
DELPHI TA5316 Cross References
DELPHI TA5316 Fits Vehicles
- Jeep Utility Wagon (1963-1964)
- Jeep Truck (1963-1964)
- Jeep Universal Truck (1963-1969)
- Willys MB (1941-1942)
- Jeep J-3600 (1965)
- Jeep J-4800 (1971-1973)
- Jeep J-4700 (1971-1973)
- Jeep J-4600 (1971-1973)
- Jeep CJ6A (1966-1968)
- Jeep J-4500 (1971-1973)
- Jeep J-200 (1963-1965)
- Jeep J-3500 (1965)
- Jeep CJ5A (1966-1968)
- Jeep J-2800 (1965)
- Jeep J-330 (1963-1965)
- Jeep J-230 (1963-1965)
- Jeep J-3700 (1965)
- Jeep J-3800 (1965, 1971)
- Jeep J-2700 (1965)
- Jeep J-310 (1963-1965)
- Jeep J-210 (1963-1965)
- Jeep J-320 (1963-1965)
- Jeep J-220 (1963-1965)
- Jeep J-300 (1963-1965)
- Jeep 6-230 (1963-1965)
- Jeep F-134 (1963-1965)
- Jeep 6-226 (1956-1964)
- Jeep 475 (1956)
- Jeep Willys (1943-1944, 1947-1958)
- Jeep Wagoneer (1972-1973)
- Jeep Universal (1961-1967)
- Jeep Jeepster (1966-1971)
- Jeep J-2600 (1965, 1972-1973)
- Jeep F4 (1957-1960)
- Jeep J-2500 (1965, 1971-1973)
- Jeep DJ3 (1959-1965)
- Jeep Gladiator (1963-1965)
- Jeep Dispatcher (1963-1965)
- Jeep Commando (1966-1973)
- Jeep FC170 (1957-1964)
- Jeep FC150 (1957-1964)
- Jeep CJ3 (1959-1966)
- Jeep Scrambler (1981-1985)
- Jeep CJ6 (1959-1975)
- Jeep CJ7 (1976-1986)
- Jeep CJ5 (1959-1983)
