(888) 312-8812 Login SignupDELPHI AF10489 Mass Air Flow Sensor
$21999
Limited availability at this price!
In Stock
Get it by Tuesday, Feb 10
DELPHI AF10489 Part Description
Manufacturer
Product Description
Mass Air Flow Sensor
Features & Benefits
- Delphi mass air flow sensors are the global benchmark for accuracy and signal noise
- Delphi mass air flow sensors feature high quality sensing elements for outstanding performance over a wide range of ambient temperatures
- Delphi is a manufacturer of OE mass air flow sensors since their first use over 30 years ago
- All parts are calibrated and tested to match the OE part
- Probe solution offered wherever possible to reduce repair time by eliminating the need to replace the flow tube
- Delphi OE technology validated to match the vehicle applications
DELPHI AF10489 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Package Contents | Mass Air Flow Sensor - Complete Assembly |
| Color | Black |
| Housing Included | No |
| Terminal Type | Blade |
| Mounting Hardware Included | No |
| Universal Or Specific Fit | Specific |
| Grade Type | Standard Replacement |
| Connector Quantity | 1 |
| Connector Shape | Oval |
| Mounting Hole Quantity | 2 |
| Terminal Quantity | 5 |
| Connector Gender | Female |
| Terminal Gender | Male |
| Wiring Harness Included | No |
| Mounting Type | Bolt-On |
| Mounting Bracket Included | No |
| Sensor Casing Length | 46 MM |
| Sensor Casing Width | 40 MM |
| Voltage | 12.0 2H |
| Gasket Or Seal Included | Yes |
| Bolt Hole Center To Bolt Hole Center | 40.20 MM |
| Mounting Hole Diameter | 0.1 IN |
| Seal Outside Diameter | 39.5 mm |
| Seal Quantity | 1 |
| Sensor Casing Length | 1.8 IN |
| Sensor Casing Width | 1.5 IN |
| Bolt Hole Center To Bolt Hole Center | 1.50 IN |
| Mounting Hole Diameter | 4.5 MM |
| Seal Outside Diameter | 1.5 IN |
| Intake Air Temperature (IAT) Included | Yes |
Additional Information
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9026800000 |
| Harmonized Tariff Code (HTS) | 9026208000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| UPC | 00689604283868 |
| VMRS Code | 045021019 |
| UNSPSC | 41111931 |
DELPHI AF10489 Cross References
| Brand | Part Number |
|---|---|
| BWD | MA1211 |
| Carquest | MQ7395 |
| HITACHI | MAF0030, MAF0057 |
| Hitachi Automotive | MAF0030, MAF0057 |
| N/A | 245-1254, MAS0516, MF21188, 245-1255, MF21349 |
| NGK SPARK PLUGS | MG0192 |
| NTK | MG0192 |
| Porsche | 955 606 123 50 |
| SPECTRA PREMIUM | MA454 |
| STANDARD IGNITION | MAS0379, MAS0516 |
| Spectra Premium | MA477 |
| Standard Motor Products | MAS0379 |
| Volkswagen | 059 906 461 N, 420 133 471 |
DELPHI AF10489 Fits Vehicles
- Audi A8 Quattro (2015-2016)
- Audi A7 Quattro (2014-2016)
- Audi A6 Quattro (2014-2016)
- Audi Q5 (2014-2016)
- Porsche Cayenne (2013-2016)
- Audi R8 (2010-2012, 2014-2015, 2017-2018, 2020-2021)
- Volkswagen Touareg (2009-2016)
- Audi Q7 (2009-2015)
