Vibrant Performance 2873 - 90 Degree Tight Radius 6061 Cast Aluminum Elbow; 2.5 in. O.D.;
- Part Number
- 2873
- Manufacturer
- VIBRANT PERFORMANCE
- Description
-
90 Degree Tight Radius 6061 Cast Aluminum Elbow; 2.5 in. O.D.;
details
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
VIBRANT PERFORMANCE part description
Product Description
90 Degree Tight Radius 6061 Cast Aluminum Elbow
Features & Benefits
- Cast Aluminum
- Constructed from 6061 aluminum
- 1 Year Limited Warranty
- Fabricators can count on material consistency and dimensional accuracy
- Mirror polished
- Requires minimal preparation for welding and fabrication
Product Attributes
| Bend Angle | 90 Degree |
| Center Line Radius | 2.000 in. (50.8mm) |
| Finish | Raw |
| Gauge | 16 |
| Inlet Diameter | 2.500 in. (63.5mm) |
| Leg/straight Length | 0.500 in./12.7mm |
| Material | 6061 Aluminum |
| Outlet Diameter | 2.500 in. (63.5mm) |
| Outside Diameter | 2.500 in. |
| Thickness | 1.5mm |
| WARNING CA Proposition 65 | No |
| Add-On | N/A |
| Bend Angle | 90 DEG |
| Elbow O.d. | 2.5 IN |
| Leg Length | 0.5 IN |
| Prop 65 Yes/no | No |
| Sale Segment | Aluminum Tubing |
| Wall Thickness | 0.125 IN |
| Web Category | Aluminum Tubing, Bends and Accessories |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 7616999090 |
| Harmonized Tariff Code (Schedule B) | 7616995190 |
| Harmonized Tariff Code (HTS) | 7616995190 |
| NAFTA Preference Criterion Code | B |
| Warranty Special | 1 Year Limited Warranty |
| Warranty Special UOM | TX |
| Warranty Time | 1 |
| Warranty Time UOM | YR |
| UPC | 00690092180973 |
