(888) 312-8812 Login SignupCENTRIC 306.13690 Centric Heavy Duty 26K Pad Air Disc ADB22x
Tap to view 1 more
$260.36
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 306.13690 Part Description
Manufacturer
Product Description
Centric Heavy Duty 26K Pad Air Disc ADB22x
Features & Benefits
- Para-aramid friction compounds are specially formulated to provide linear response at both cold and hot temperatures. Positive Mold Technology. Precision cut backing plates. Scorched for improved pad/rotor bed-in.
CENTRIC 306.13690 Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Hardware Kit Number [cntrc] | 117.86001 |
| Weight [cntrc] Lbs | 21.70 |
| Weight [cntrc] Kgs | 9.86 |
| Product Grade [cntrc] | Fleet |
| Pad Wear Sensor Included | No |
| Friction Material Composition | Semi-Metallic |
| Mounting Hardware Included | Yes |
| Pad Shims Included | No |
| Friction Material Attachment | Integrally Molded |
| Pad Quantity | 4 |
| Prepared For Pad Wear Sensor | Yes |
| Outer Pad Height | 108.000 MM |
| Outer Pad Height | 4.252 IN |
| Inner Pad Height | 108.000 MM |
| Inner Pad Height | 4.252 in |
| Outer Pad Width | 210.300 MM |
| Outer Pad Width | 8.280 IN |
| Inner Pad Width | 210.300 MM |
| Inner Pad Width | 8.280 in |
| Outer Pad Overall Thickness | 29.600 MM |
| Outer Pad Overall Thickness | 1.165 in |
| Inner Pad Overall Thickness | 1.165 IN |
| Inner Pad Overall Thickness | 29.600 MM |
Additional Information
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305090 |
| UPC | 00889590305647 |
CENTRIC 306.13690 Cross References
| Brand | Part Number |
|---|---|
| N/A | SSP1369HD |
| TORQSTOP | 29D1369 |
CENTRIC 306.13690 Fits Vehicles
- Freightliner 108SD (2012-2017)
- Freightliner 114SD (2012-2017)
- Freightliner B2 (2005-2023)
- Freightliner Cascadia (2008-2023)
- Freightliner Century Class (2005-2011)
- Freightliner Columbia (2005-2020)
- Freightliner Coronado (2005-2020)
- Freightliner M2 (2015-2021)
- Freightliner M2 100 (2005-2006)
- Freightliner M2 106 (2005-2023)
- Freightliner M2 112 (2005-2023)
- Freightliner S2C (2013-2022)
- Freightliner S2G (2014-2022)
- Freightliner S2RV (2018-2022)
- Freightliner XB Line (2005, 2009-2015)
- Freightliner XB Raised Rail (2005-2008)
- Freightliner XB Straight Rail (2005-2022)
- Freightliner XBA (2015-2016)
- Freightliner XC (2005)
- Freightliner XC Formed Rail (2005-2007)
- Freightliner XC Lowered Rail (2007-2017)
- Freightliner XC Modular Rail (2008-2018)
- Freightliner XC Raised Rail (2005-2018)
- Freightliner XC Straight Rail (2005-2018)
- International Durastar (2015-2018)
- International HV513 (2019-2021)
- International HV607 (2019-2021)
- International HV613 (2019-2021)
- International HX515 (2017-2018)
- International HX520 (2018-2021)
- International HX615 (2017-2021)
- International HX620 (2017-2021)
- International LT625 (2017-2020)
- International ProStar (2017-2020)
- International TranStar (2015-2018)
- International WorkStar 7300 (2015-2018)
- International WorkStar 7400 (2015-2018)
- International WorkStar 7600 (2015-2018)
- Kenworth K270 (2014-2023)
- Kenworth K370 (2014-2023)
- Kenworth T2000 (2005-2010)
- Kenworth T370 (2014-2019)
- Kenworth T660 (2008-2019)
- Kenworth T680 (2013-2023)
- Kenworth T800 (2005-2017, 2019-2023)
- Kenworth T880 (2014-2017, 2019-2023)
- Kenworth W900 (2005-2023)
- Kenworth W990 (2019-2023)
- Mack CHU (2008-2019)
- Mack CXU (2008-2019)
- Mack Pinnacle (2018-2023)
- Peterbilt 348 (2011-2018)
- Peterbilt 365 (2011-2017)
- Peterbilt 367 (2011-2020)
- Peterbilt 382 (2011-2017)
- Peterbilt 384 (2008-2015)
- Peterbilt 386 (2006-2015)
- Peterbilt 387 (2005-2011)
- Peterbilt 388 (2008-2015)
- Peterbilt 389 (2008-2020)
- Peterbilt 567 (2014-2020)
- Peterbilt 579 (2013-2020)
- Volvo VNL (2005-2018)
- Volvo VNM (2005-2018)
- Volvo VNR (2018)
- Volvo VT (2006-2010)
- Western Star 4900EX (2013-2018)
- Western Star 4900FA (2013-2018)
- Western Star 4900SA (2013-2018)
- Western Star 5700XE (2016-2018)
- American Coach American Tradition (2021-2022)
- Blue Bird All American FE (2005-2018)
- Blue Bird All American RE (2005-2017)
- Blue Bird Vision School Bus (2012-2018)
- Coachmen Sportscoach RD (2021)
- Fleetwood Discovery (2020-2021)
- Fleetwood Discovery LXE (2021-2022)
- Fleetwood Discovery LXE Anniversary Edition (2021)
- Fleetwood Pace Arrow (2020-2022)
- Fleetwood Pace Arrow LXE (2020-2021)
- Holiday Rambler Endeavor (2020-2022)
- Sterling Truck Acterra (2005-2010)
- Sterling Truck Acterra 5500 (2005-2007)
- Sterling Truck Acterra 6500 (2005-2007)
- Sterling Truck Acterra 7500 (2005-2007)
- Tiffin Allegro Breeze (2020-2022)
- Tiffin Allegro Bus (2019)
- Tiffin Allegro Red (2019-2021)
- Tiffin Allegro Red 340 (2019-2021)
- Tiffin Allegro Red 360 (2022-2023)
- Tiffin Phaeton (2019-2021)
- Tiffin Zephyr (2019)
CENTRIC 306.13690 Customer Reviews
No reviews yet
Be the first to review this product!
CENTRIC 306.13690 Questions & Answers
No questions yet
Be the first to ask a question about this product!
