Leece Neville AVI150S1121HP - A150S121 - PRESTOLITE LEECE NEVILLE IDLE PRO 24V 180A BRUSH ALTERNATOR
- Part Number
- AVI150S1121HP
- Manufacturer
- LEECE NEVILLE
- Description
-
A150S121 - PRESTOLITE LEECE NEVILLE IDLE PRO 24V 180A BRUSH ALTERNATOR
details
$1,08649
MSRP: $1,243.88
Save: $157.39
Limited Availability
LEECE NEVILLE part description
Product Specifications
| Spec | Value |
|---|---|
| Item number | AVI150S1121HP |
| Sales number | A150S121 |
| Series number | AVI147 |
| System voltage | 24 |
| Output | 180 |
| Mounting style | SPOOL |
| Dimensions in | MILLIMETERS |
| Rotation | CLOCKWISE |
| Housing coating | PAINTED |
| UL Approved | No |
| Spool length | 80MM |
| Positive stud size | M8 |
| Negative stud size | WIRING HARNESS |
| Rectifier location | INTEGRAL |
| Shaft diameter | 17mm |
| Excitation type | |
| Regulator location | |
| Regulator number | |
| Diode trio | No |
| Pulley included | No |
| Lamp driver | No |
| Adjustable regulator | No |
| Remote sense | No |
| Smart check | No |
| Batteryless | No |
Similar Product
| We have another model that is equivalent to AVI150S1121HP | |
|---|---|
| AVI150S1104HP | |
| Volts | 24 |
| Amp | 190 |
A division of Prestolite Electric Incorporated, Leece-Neville® is a well-known supplier of starters, alternators, and other electrical equipment for transportation, industrial, and military applications. This brand shares the same "Easy to do Business" philosophy with Prestolite and the same manufacturing and distribution centers in America, Europe, Canada, China, Hong Kong, and Mexico. With an industry history that dates back to 1919, Leece-Neville has its glory days in the production of electrical starters, voltage regulators, and generators for trucks, airplanes, as well as industrial and marine equipment during the World War II. In July 1987, Leece-Neville was acquired by Prestolite Electric, which widened its reach to the international market and made the Leece-Neville name globally recognized.
