(888) 312-8812 Login SignupTYC 2427 Radiator Assembly
Tap to view 2 more
$16249
Limited availability at this price!
In Stock
Get it by Monday, Feb 16
TYC 2427 Part Description
Manufacturer
Product Description
Radiator Assembly
Features & Benefits
- OE-comparable core dimensions to achieve sufficent surface area for optimal cooling.
- OE-comparable core dimensions to achieve sufficient surface area for optimal cooling. Rigorous and accelerated cycling tests to ensure product service quality and durability. Individually leak-tested to ensure product has no leaks.
- Rigorous and accelerated cycling tests to ensure product service quality and durability.
- Individually leak-tested to ensure product has no leaks.
TYC 2427 Specifications
Product Attributes
| Core Thickness (in) | 1.02 |
| Toc Outlet Type | Tube fitting |
| Total Fin Row Count | 72 |
| Flow Configuration | Downflow |
| Transmission Oil Cooler Type | Concentric Oil Cooler |
| REMARKS | Also Fit #2153 |
| Accessories Included | Sensor plug (M16) x 1 |
| Bottom Header | 2.03x29.43 |
| Toc Outlet Diameter (in) | 0.39 |
| Toc Inlet Diameter (in) | 0.39 |
| Inlet Connection Type | Hose Clamp |
| Tube Width X Height | 26x2 |
| Top Header | 2.03x29.43 |
| Total Tube Count | 71 |
| No. Of Rows | 1 |
| Outlet Diameter (in) | 1.38 |
| Toc Distance (in) | 14.76 |
| Transmission Oil Cooler Included | Yes |
| Engine Oil Cooler Included | No |
| Core Length (in) | 17.72 |
| Core Material | Aluminum |
| Outlet Connection Type | Hose Clamp |
| Fin Wave Height (in) | 0.31 |
| Tube Count (every 4") | 10 |
| Toc Inlet Type | Tube fitting |
| Find Wave Pitch | 2.7 |
| Fin Count (every 4") | 75 |
| Core Height (in) | 28.27 |
| Inlet Diameter (in) | 1.38 |
Additional Information
| Country of Origin (Primary) | CN |
| UPC | 00762405252254 |
TYC 2427 Cross References
| Brand | Part Number |
|---|---|
| APDI | 8012153 |
| APDI RADS | 8012153 |
| CSF | 19, 2817 |
| DENSO | 221-3101 |
| DPI (DataPoint Inc) | 2153 |
| GLOBAL PARTS DISTRIBUTORS | 2427C |
| Partslink | TO3010164 |
| Performance Radiator | 2153 |
| Proliance | 432313 |
| REACH COOLING | 41-2427, 41-2153 |
| Reach Cooling | REA41-2427A |
| SPECTRA PREMIUM | CU2153 |
| Silla Cooling | 2728 |
| Spectra Premium | CU2427 |
| Toyota | 16400-0A210 |
| UNIVERSAL AIR CONDITIONER (UAC) | RA2153C |
| Vista Pro | 432313 |
TYC 2427 Fits Vehicles
- Toyota Sienna (1998-2003)
TYC 2427 Customer Reviews
No reviews yet
Be the first to review this product!
TYC 2427 Manufacturer Information
TYC Genera® delivers automotive and truck parts and accessories that are meticulously designed, assembled, and tested to meet or exceed the industry's strict quality control standards. Backed by over 40 years of experience in producing automotive lamps, TYC/Genera continuously grows, expanding its product lines to offer starting and charging solutions, fuel pumps, mirrors, window regulators, and HVAC solutions. TYC owes its constant growth to its ability to foresee and adapt to industry changes. This brand makes use of revolutionary manufacturing technologies, such as SCARA robotics, and end-user technologies like HID, AFS, and LED lighting to produce and supply the industry with the most technologically advanced solutions.
TYC 2427 Questions & Answers
No questions yet
Be the first to ask a question about this product!
