(888) 312-8812 Login SignupHALDEX AL430668 FFABS Valve - 4-Port ABS Valve, Service Brake Priority, 12V, 1/2" / 3/4" Nipple
$59249
Limited availability at this price!
In Stock
Get it by Tuesday, Dec 30
HALDEX AL430668 Part Description
Manufacturer
Product Description
FFABS Valve
Application Summary
Replaces AL430611,Patented FFABS Valve with integral Spring Brake Control function.
Features & Benefits
- Patented and comes with integral spring brake control function
- Guarantees easy serviceability with its pre-installed reservoir nipple with swivel and lock-nut feature
- Fitted with filters in both the control and supply ports
- With production part number engraved on the metal tag
- Made standard with filters in the control and supply ports
Haldex Full-Function ABS (FFABS) Valve
Crafted to the industry's highest standards for performance, reliability, and safety, the Haldex Full-Function ABS valve provides you with a dependable performance at all times. This component expedites service replacement with its pre-installed combination nipple that works for two ports of different sizes.
HALDEX AL430668 Specifications
Product Attributes
| Control Port Diameter | 3/8 in. |
| Delivery Port Diameter | 4 @ 3/8 in. |
| Freight Class | 70 |
| Opening Pressure | 4.0 PSI |
| Reservoir Port Diameter | 1 @ 1/2 in., 1 @ 3/4 in. (Nipple) |
| Spring Brake Port Diameter | 4 @ 3/8 in. |
| Supply Port Diameter | 3/8 in. |
| Valve Type | 4-Port ABS Valve |
| Voltage | 12V |
| Delivery Port | 3/8" (4) |
| Crack Pressure | 4.0 PSI |
| OEM Part Number | N4306KD |
| Supply Port | 3/8" (1) with Filter |
| Valve Specifications | 4-Port ABS Valve - Service Brake Priority |
| Spring Brake Port | 3/8" (4) |
| Reservoir Port | 1/2" / 3/4" Nipple |
| Control Port | 3/8" |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8481200060 |
| Harmonized Tariff Code (HTS) | 8481200060 |
| Remanufactured Part | N |
| Warranty Distance | 100000 |
| Warranty Distance UOM | MI |
| Warranty Special | 36 MO, 200,000 MI=ABS - Antilock Braking Systems Including Haldex TRS (Valves, ECUs and Looms Only). 12 MO, 100,000 MI= All Other ABS - Antilock Braking Systems Components. See L20221W.pdf for warranty details |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| UPC | 00767653310954 |
| VMRS Code | 013011085 |
HALDEX AL430668 Part Interchanges
| Brand | Part Number |
|---|---|
| N/A | AL430667 |
| Haldex | AL430667, N4306KC, N4306KD |
| Midland | AL430667, AL430668, N4306KA, N4306KB |
| MIDLAND | AL430667, AL430668, N4306KA, N4306KB |
HALDEX AL430668 Cross References
We have 4 alternatives for the AL430668 by HALDEX:
HALDEX AL430668 Customer Reviews
No reviews yet
Be the first to review this product!
HALDEX AL430668 Manufacturer Information
Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
