(888) 312-8812 Login SignupGATES 39396 DriveAlign Automatic Belt Drive Tensioner
Tap to view 6 more
$22099
Limited availability at this price!
In Stock
Get it by Thursday, Feb 12
GATES 39396 Part Description
Manufacturer
Product Description
DriveAlign Automatic Belt Drive Tensioner
Application Summary
2020-14 Toyota, Corolla, 4-Cyl. 1.8 L, Tensioner Assy.
Features & Benefits
- Comprehensive line includes parts to fit cars, vans, SUVs and light trucks, domestic and import (European and Asian)
- Manufactured using the same or improved technology and quality materials as the Original Equipment Manufacturer (OEM) part, assuring a factory match
- Patented labyrinth seal protects internal components to meet or exceed OE life expectancy requirements
- Patented vibration-damping system absorbs extreme vibration to improve tensioner, as well as belt and accessory, life
- Torsional round spring design provides reliability as well as consistent tension
GATES 39396 Specifications
Product Attributes
| Grade Type | OE Exact |
| Pulley Quantity | 1 |
| Groove Quantity | 0 |
| Material | Thermoplastic |
| Contact Surface | Smooth/Backside |
| Pulley 1 Flanged | No |
| Outside Diameter | 2.56 IN |
| Bearing Bore Inside Diameter | .67 IN |
| Width | .94 IN |
| Belt Type | V-Ribbed |
| Mounting Hole Quantity | 2 |
| Contents | Tensioner Assy. |
| Pulley 1 Groove Quantity | 0 |
| Outside Diameter 1 (in) | 2.56 |
| Outside Diameter 1 (mm) | 65 |
| Width 1 (in) | .94 |
| Width 1 (mm) | 24 |
| Bearing Bore Inside Diameter | 17 MM |
Additional Information
| Country of Origin (Primary) | CA |
| Harmonized Tariff Code (Schedule B) | 8708998180 |
| Stock Status | S |
| UPC | 00770075729433 |
| VMRS Code | 042003076 |
| UNSPSC | 26111805 |
GATES 39396 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 39396 |
| BANDO | 780091 |
| CONTINENTAL AG | 49843 |
| Continental Belt | 49843 |
| Dayco | 89688 |
| GOODYEAR BELTS | 55217 |
| General Motors | 1662037030 |
| Goodyear | 49843 |
| INA | FT06701 |
| Litens | 999915A |
| NAPA Belts/Hose | 39396 |
| Tendeco | 999915 |
| Toyota | 166200T010, 1662037010, 1662037011, 1662037030 |
GATES 39396 Fits Vehicles
- Toyota Corolla iM (2017-2018)
- Toyota C-HR (2018-2022)
- Scion iM (2016)
- Toyota Corolla (2014-2020)
