Standard Ignition UF803 - Coil on Plug Coil
- Part Number
- UF803
- Manufacturer
- STANDARD IGNITION
- Description
-
Coil on Plug Coil
details
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
STANDARD IGNITION part description
Product Description
Coil on Plug Coil
Features & Benefits
- Premium components ensure optimum performance and long service life under all operating conditions
- Neodymium in the core creates the strongest magnetic field and produces max high voltage output at all speeds
- High-dielectric epoxy injected into case and pulled into vacuum to eliminate air pockets and prevent moisture intrusion or thermal breakdown
- Reinforced bobbins prevent voltage flashover for extended service life
- As a tier I manufacturer with engineering and design capabilities second to none, our ignition coils are made to the highest quality standards
- Advanced bobbin technology, highly specialized silicone magnetic steel core, and optimized winding all provide an accurate high energy output to restore engine performance
- Engineered and tested to meet OE spark energy output, impedance, and durability in all operating conditions.
- Engineered specifically for import vehicles
- High-dielectric epoxy injected into case and pulled into vacuum to eliminate air pockets and prevent moisture intrusion or internal energy loss
- High-temp boot prevents high-voltage leaks, while stainless-steel spring with internal ferrite noise suppressor prevents radiofrequency interference (RFI)
- Our ignition coils use 100% pure copper windings in the primary and secondary bobbins to improve durability and provide higher resistance to internal shorts and dielectric breakdown
Product Attributes
| Voltage | 12 |
| Color | Black |
| Ignition Type | Distributorless |
| Coil Type | Electronic |
| Terminal Type | Blade |
| Mounting Hardware Included | No |
| Connector Quantity | 1 |
| Connector Shape | Square |
| Mount Type | Bolt On |
| Terminal Quantity | 2 |
| Connector Gender | Female |
| Terminal Gender | Male |
| Mounting Bracket Included | Yes |
| Coil Included | Yes |
| Grease Pack | No |
| Instructions Included | No |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8511300080 |
| Warranty Distance | 36000 |
| Warranty Distance UOM | MI |
| Warranty Time | 36 |
| Warranty Time UOM | MO |
| UPC | 00033086119274 |
Part Interchanges
Fits Vehicles
- Renault Laguna (2003-2006)
- Peugeot 607 (2006-2008)
- Peugeot 407 (2006-2008)
- Peugeot 406 (2002-2005)
