(888) 312-8812 Login SignupDELPHI TD770W Suspension Stabilizer Bar Link Kit
Tap to view 3 more
MSRP: $20.45
$1499
Save $5.46
Limited availability at this price!
In Stock
Get as soon as Friday, Nov 20
DELPHI TD770W Part Description
Manufacturer
Product Description
Suspension Stabilizer Bar Link Kit
Features & Benefits
- Delphi sway bar links are fatigue tested to avoid failure
- Sway bar links manufactured with ultrasonic molding to help prevent future weld breakage
- Delphi machines to micron tolerances to guarantee durability and smooth joint operation
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TD770W Specifications
Product Attributes
| Position(s) | Front, Rear. For the position specific to your vehicle, refer to the Applications. |
| Item Grade | Standard Replacement |
| Bushing Outside Diameter | 1.22 IN |
| Bushing Outside Diameter | 31.0 MM |
| Bushing Color | Black |
| Length | 10.709 IN |
| Length | 272.0 MM |
| End 1 Type | Bushing |
| End 2 Type | Bushing |
| Pre-Greased | No |
| Bushings Included | Yes |
| Dust Boot Included | No |
| Grease Fittings Included | No |
| Sleeve Length | 5.984 IN |
| Sleeve Length | 152.0 MM |
| Bolt Thread Size | 3/8'' |
| Sleeve Diameter | 0.512 IN |
| Sleeve Diameter | 13.0 MM |
| Center Bolt Head Size | 14 |
| Washers Included | Yes |
| Grade Type | Standard Replacement |
| Bolts Included | Yes |
| Greaseable | No |
| Bearing Material | Natural Rubber (NR) |
| Bushing Material | Natural Rubber (NR) |
| Bolt Length | 10.709 IN |
| Bolt Length | 272.0 MM |
| Bolt Thread Diameter | 0.375 IN |
| Bolt Thread Pitch | 1.058 MM |
| Locking Nuts Included | Yes |
| Bushing Inside Diameter | 0.394 IN |
| Bushing Inside Diameter | 10.0 MM |
| Bolt Thread Diameter | 9.52 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited |
| Warranty Special UOM | LT |
| Country of Origin (Primary) | TR |
| UPC | 00689604275245 |
| VMRS Code | 016004023 |
| UNSPSC | 25172001 |
DELPHI TD770W Cross References
DELPHI TD770W Fits Vehicles
- American Motors Eagle (1980-1988)
- Ford Taurus (1986-2007)
- Lincoln Continental (1984-1991)
- Lincoln Mark VII (1984-1992)
- Mercury Sable (1986-2005)
