(888) 312-8812 Login SignupDELPHI TC1626 Ball Joint
Tap to view 2 more
MSRP: $54.18
$3799
Save $16.19
Limited availability at this price!
In Stock
Get it by Thursday, Feb 19
DELPHI TC1626 Part Description
Manufacturer
Product Description
Ball Joint
Features & Benefits
- Delphi ball joints manufactured with high quality forgings for increased strength and smooth operation
- Ball joints utilize chloroprene rubber boots which improves durability, preventing premature failure
- Delphi machines to micron tolerances to guarantee durability and smooth joint operation
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC1626 Specifications
Product Attributes
| Position(s) | Front Lower |
| Item Grade | Standard Replacement |
| Material | Ball Material - Alloy Steel SAE 5140, Housing Material - Carbon Steel SAE 1040 |
| Maximum Outside Diameter | 2.165 IN |
| Maximum Outside Diameter | 55.00 MM |
| Color | Gray |
| Stud Thread Diameter | 0.563 IN |
| Castle Nut Included | Yes |
| Grease Fitting Included | No |
| Suspension Grade Type | Standard Replacement |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 55 MM |
| Cotter Pin Included | Yes |
| Cotter Pin Hole | Yes |
| Mounting Hardware Included | Yes |
| Washers Included | Yes |
| Height | 4.055 IN |
| Height | 67.00 MM |
| Nuts Included | Yes |
| Adjustable | No |
| Greaseable | No |
| Stud Thread Length | 1.004 IN |
| Stud Type | Threaded |
| Mounting Type | Press-In |
| Dust Boot Material | Rubber |
| Mounting Bolts Included | No |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| Stud Taper Per Foot | 0.167 IN |
| Stud Tapered End 2 Diameter | 0.642 IN |
| Stud Tapered End 2 Diameter | 16.3 MM |
| Stud Tapered End 1 Diameter | 0.78 IN |
| Stud Tapered End 1 Diameter | 19.8 MM |
| Stud Threads Per Inch | 18 |
| Length | 4.060 IN |
| Length | 103.12 MM |
| Stud Thread Diameter | 14.3 MM |
| Stud Thread Length | 25.5 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604277140 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
DELPHI TC1626 Cross References
DELPHI TC1626 Fits Vehicles
- Dodge Durango (1998-1999)
- Dodge Dakota (1987-1999)
