DELPHI TC1651 Part Description
Manufacturer
Product Description
Ball Joint
Features & Benefits
- Delphi ball joints manufactured with high quality forgings for increased strength and smooth operation
- Ball joints utilize chloroprene rubber boots which improves durability, preventing premature failure
- Delphi machines to micron tolerances to guarantee durability and smooth joint operation
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC1651 Specifications
Product Attributes
| Position(s) | Front Lower |
| Item Grade | Standard Replacement |
| Material | Steel |
| Maximum Outside Diameter | 2.110 IN |
| Maximum Outside Diameter | 53.60 MM |
| Color | Gray |
| Stud Thread Diameter | 0.63 IN |
| Stud Thread Diameter | 16 MM |
| Castle Nut Included | Yes |
| Grease Fitting Included | Yes |
| Suspension Grade Type | Standard Replacement |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 81 MM |
| Cotter Pin Included | Yes |
| Cotter Pin Hole | Yes |
| Mounting Hardware Included | Yes |
| Mounting Bolt Length | 1.634 IN |
| Mounting Bolt Length | 41.50 MM |
| Washers Included | No |
| Height | 4.264 IN |
| Height | 108.30 MM |
| Nuts Included | Yes |
| Mounting Hole Quantity | 4 |
| Adjustable | No |
| Greaseable | Yes |
| Stud Thread Length | 0.85 IN |
| Stud Thread Length | 21.6 MM |
| Wrench Size | 17mm |
| Stud Type | Threaded |
| Mounting Type | Bolt-In |
| Distance Between Mounting Holes | 27.00 MM |
| Dust Boot Material | Rubber |
| Mounting Bolt Shank Diameter | 0.394 IN |
| Mounting Bolt Shank Diameter | 10.00 MM |
| Mounting Bolt Head Diameter | 0.709 IN |
| Mounting Bolt Head Diameter | 18.00 MM |
| Mounting Bolts Included | Yes |
| Mounting Bolt Thread Pitch | 1.25 MM |
| Mounting Bolt Thread Length | 1.378 IN |
| Mounting Bolt Thread Length | 35.00 MM |
| Mounting Bolt Thread Diameter | 10.00 MM |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| Stud Tapered End 2 Diameter | 0.843 IN |
| Stud Tapered End 2 Diameter | 21.4 MM |
| Stud Tapered End 1 Diameter | 0.701 IN |
| Stud Tapered End 1 Diameter | 17.8 MM |
| Stud Thread Pitch | 1.5 MM |
| Mounting Bolt Thread Diameter | 0.390 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604276938 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
DELPHI TC1651 Cross References
| Brand | Part Number |
|---|---|
| Chrysler | 52038742, 5205 9018, 5205 9019, 52106 116AA, 52106 117AA |
| DORMAN | B7241, B7241PR |
| Dorman | 520-349, 520-350 |
| MAS Industries | B7241, CB81233, CB81233PR, CB81234, CB81234PR |
| MOOG Chassis Products | K7241, K7393, RK620474, RK620475 |
| Mevotech | MK7241 |
| N/A | GK7393, BJ81375, GK7241, BJ81375XL, B7241PR, 610.67011, MK7393 |
| TRW | JBJ1011, JBJ905 |
DELPHI TC1651 Fits Vehicles
- Dodge Durango (1999-2003)
- Dodge Dakota (1997-2004)
