Item Grade	Standard Replacement
Position(s)	Front Lower
Material	Steel
Maximum Outside Diameter	4.823 IN
Maximum Outside Diameter	122.50 MM
Color	Black
Stud Thread Diameter	0.709 IN
Stud Thread Diameter	18 MM
Castle Nut Included	Yes
Grease Fitting Included	No
Suspension Grade Type	Standard
Bushings Included	No
Dust Boot Included	Yes
Ball Joint Assembly	Yes
Width	107 MM
Cotter Pin Included	Yes
Cotter Pin Hole	Yes
Mounting Hardware Included	Yes
Mounting Bolt Length	1.870 IN
Mounting Bolt Length	47.50 MM
Washers Included	Yes
Height	4.240 IN
Height	107.70 MM
Nuts Included	Yes
Mounting Hole Quantity	4
Adjustable	No
Greaseable	No
Stud Thread Length	1.083 IN
Stud Thread Length	27.5 MM
Wrench Size	24mm
Stud Type	Threaded
Mounting Type	Bolt-In
Distance Between Mounting Holes	45.00 MM
Dust Boot Material	Rubber
Mounting Bolt Shank Diameter	0.472 IN
Mounting Bolt Shank Diameter	12.00 MM
Mounting Bolt Head Diameter	0.831 IN
Mounting Bolt Head Diameter	21.10 MM
Mounting Bolts Included	Yes
Mounting Bolt Thread Pitch	1.25 MM
Mounting Bolt Thread Length	1.181 IN
Mounting Bolt Thread Length	30.00 MM
Mounting Bolt Thread Diameter	12.00 MM
Mount Plate Included	No
Tapered Stud	Yes
Stud Tapered End 2 Diameter	0.906 IN
Stud Tapered End 2 Diameter	23 MM
Stud Tapered End 1 Diameter	0.811 IN
Stud Tapered End 1 Diameter	20.6 MM
Stud Thread Pitch	1.5 MM
Mounting Bolt Thread Diameter	0.470 IN

Harmonized Tariff Code (Schedule B)	8708807000
Harmonized Tariff Code (HTS)	8708806590
Warranty Special	Limited Lifetime
Warranty Special UOM	LF
Country of Origin (Primary)	TR
UPC	00689604259962
VMRS Code	016001015
UNSPSC	25174203

Delphi TC691 - Ball Joint

Ball Joint
