DELPHI TC1243 Part Description
Manufacturer
Product Description
Ball Joint
Features & Benefits
- Delphi ball joints manufactured with high quality forgings for increased strength and smooth operation
- Ball joints utilize chloroprene rubber boots which improves durability, preventing premature failure
- Delphi machines to micron tolerances to guarantee durability and smooth joint operation
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC1243 Specifications
Product Attributes
| Position(s) | Front Lower |
| Item Grade | Standard Replacement |
| Material | Steel |
| Maximum Outside Diameter | 2.165 IN |
| Maximum Outside Diameter | 55.00 MM |
| Castle Nut Included | No |
| Grease Fitting Included | No |
| Suspension Grade Type | Standard Replacement |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 55 MM |
| Type | Premium |
| Cotter Pin Included | No |
| Cotter Pin Hole | No |
| Mounting Hardware Included | Yes |
| Washers Included | No |
| Height | 2.165 IN |
| Height | 55.00 MM |
| Nuts Included | Yes |
| Mounting Hole Quantity | 0 |
| Adjustable | No |
| Greaseable | No |
| Stud Thread Length | 0.724 IN |
| Stud Thread Length | 18.4 MM |
| Stud Type | Threaded |
| Mounting Type | Press-In |
| Dust Boot Material | Rubber |
| Bushing Quantity | 0 |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| Stud Tapered End 2 Diameter | 0.594 IN |
| Stud Tapered End 2 Diameter | 15.1 MM |
| Stud Tapered End 1 Diameter | 0.693 IN |
| Stud Tapered End 1 Diameter | 17.6 MM |
| Stud Thread Pitch | 1.25 MM |
| Length | 90.00 MM |
| Length | 3.540 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604251423 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
DELPHI TC1243 Cross References
| Brand | Part Number |
|---|---|
| Beck/Arnley | 101-4785 |
| CORTECO | 49395760 |
| DORMAN | B9855, B9855PR, 537-008 |
| Hyundai | 54503-34A00, 54503-34A01, 54530-37000, 54530-37010 |
| Import Direct | BJ06069 |
| MAS Industries | B9855 |
| MOOG Chassis Products | K9855 |
| Mevotech | MK9855 |
| N/A | B9855PR, GK9855, MS80506 |
| Raybestos Chassis | 505-1247 |
| TRW | JBJ514 |
DELPHI TC1243 Fits Vehicles
- Hyundai Sonata (1995-1998)
