Delphi TA977 - Tie Rod End
$1699
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DELPHI part description
Product Description
Tie Rod End
Product Attributes
| Position(s) | Outer |
| Item Grade | Standard Replacement |
| Color | Black |
| End 1 Gender | Male |
| End 2 Gender | Male |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Dust Boot Included | Yes |
| Width | 38.5 MM |
| Type | Straight |
| Mounting Hardware Included | Yes |
| End 2 Thread Diameter | 14.00 MM |
| End 2 Thread Diameter | 0.551 IN |
| Height | 72.60 MM |
| Housing Material | Steel |
| Tube Diameter | 14.00 MM |
| Tube Diameter | 0.551 IN |
| Adjustable | No |
| Greaseable | No |
| Weight | 0.77 lb |
| Cone Outside Diameter | 15.85 MM |
| Bearing Material | Plastic |
| End 1 Thread Direction | Clockwise (Right) |
| End 2 Thread Direction | Clockwise (Right) |
| Stud Type | Threaded |
| End 2 Thread Pitch | 1.5 MM |
| Length - Stud Center to End | 3.575 IN |
| Length - Stud Center to End | 90.80 MM |
| Dust Boot Material | Rubber |
| Tie Rod Material | Steel |
| End 1 Thread Diameter | 0.394 IN |
| End 1 Thread Diameter | 10.00 MM |
| Shank Length | 15.85 MM |
| Stud Length | 15.85 MM |
| Grade Type | Standard |
| Grade | Premium |
| Shank Length | 0.624 IN |
| Stud Length | 0.624 IN |
| Cone Outside Diameter | 0.624 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708998175 |
| Harmonized Tariff Code (HTS) | 8708998180 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604250129 |
| VMRS Code | 015004045 |
| UNSPSC | 25174205 |
Part Interchanges
- Beck/Arnley 101-3555
- Raybestos Chassis 401-1791
- MOOG Chassis Products ES2878
- Mcquay-Norris ES2878
- Citroen 9471000965
- Citroen 9471003465
- Citroen 95493208
- Citroen 95590802
- Peugeot 3817.1
- Peugeot 3817.10
- Peugeot 3817.18
- Peugeot 3817.5
- Peugeot 3817.50
- Peugeot 3817.52
- MAS Industries TO31005
- 381709
- 7704002248
- TO31005PR
- 532956
- 7943010217
- 941000965
- 9549328
- 1607316180
Fits Vehicles
- Peugeot Partner (2003-2009)
- Peugeot 306 (1997-2002)
- Peugeot 505 (1980-1990)
- Peugeot 604 (1979-1984)
- Peugeot 504 (1979-1983)
