DELPHI TA1915 Part Description
Manufacturer
Product Description
Tie Rod End
Features & Benefits
- Delphi includes the necessary accessories for a complete job
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Delphi tie rods are fatigue tested to avoid failure
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TA1915 Specifications
Product Attributes
| Position(s) | Right Outer |
| Item Grade | Standard Replacement |
| Color | Gray |
| End 2 Gender | Female |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Dust Boot Included | Yes |
| Width | 37 MM |
| Type | Bent |
| Mounting Hardware Included | Yes |
| End 2 Thread Diameter | 0.630 IN |
| End 2 Thread Diameter | 16.00 MM |
| Height | 76.40 MM |
| Housing Material | Steel |
| Tube Diameter | 0.984 IN |
| Tube Diameter | 25.00 MM |
| Adjustable | No |
| Greaseable | No |
| Weight | 1.11 lb |
| Cone Outside Diameter | 16.40 MM |
| Bearing Material | Plastic |
| End 1 Thread Direction | Clockwise (Right) |
| End 2 Thread Direction | Clockwise (Right) |
| Stud Type | Threaded |
| End 2 Thread Pitch | 1.5 MM |
| Length - Stud Center to End | 3.740 IN |
| Length - Stud Center to End | 95.00 MM |
| Dust Boot Material | Rubber |
| Tie Rod Material | Steel |
| End 1 Thread Diameter | 0.472 IN |
| End 1 Thread Diameter | 12.00 MM |
| Shank Length | 16.40 MM |
| Stud Length | 16.40 MM |
| Grade Type | Standard Replacement |
| Grade | Premium |
| Shank Length | 0.646 IN |
| Stud Length | 0.646 IN |
| Cone Outside Diameter | 0.646 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708998180 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708998175 |
| Country of Origin (Primary) | TR |
| UPC | 00689604246450 |
| VMRS Code | 015004019 |
| UNSPSC | 25174205 |
DELPHI TA1915 Cross References
| Brand | Part Number |
|---|---|
| Audi | 1K0 423 812 A, 1K0 423 812 E, 1K0 423 812 G, 1K0 423 812 J, 1K0 423 812 K, 1K0 423 812B, 1K0 423 812C, 1K0 423 812F |
| Beck/Arnley | 101-5851 |
| CORTECO | 49398648, 49398834 |
| DORMAN | TO43002, TO43002XL, 534-987 |
| Deeza | AD-T205 |
| Dorman | 534-918 |
| MAS Industries | TO43002, 534-987 |
| MEYLE | 1160200026, 1160200026HD, 116 030 0019 |
| MOOG | ES80667 |
| MOOG Chassis Products | ES800506, ES80667 |
| Mcquay-Norris | ES4442 |
| Mevotech | MS10625 |
| N/A | GS10625, TO43002XL, 612.33036 |
| Seat | 1K0 423 812 A, 1K0 423 812 E, 1K0 423 812 J, 1K0 423 812 K, 1K0 423 812B, 1K0 423 812F |
| Skoda | 1K0 423 812 G, 1K0 423 812C |
| TRW | JTE1055, JTE1053 |
| VAICO | V10-0638 |
| Volkswagen | 1K0 423 812 A, 1K0 423 812 E, 1K0 423 812 G, 1K0 423 812 J, 1K0 423 812 K, 1K0 423 812B, 1K0 423 812C, 1K0 423 812F |
DELPHI TA1915 Fits Vehicles
- Audi RS3 (2023-2024)
- Volkswagen Taos (2022-2023)
- Volkswagen Arteon (2019-2023)
- Volkswagen Tiguan Limited (2018)
- Volkswagen Golf Alltrack (2017-2019)
- Volkswagen Golf R (2012-2013, 2015-2019, 2022-2023)
- Audi A3 Sportback e-tron (2016-2018)
- Volkswagen Golf SportWagen (2015-2019)
- Audi Q3 Quattro (2015-2018)
- Audi Q3 (2015-2025)
- Audi S3 (2015-2020, 2022-2024)
- Volkswagen e-Golf (2015-2020)
- Audi A3 Quattro (2006-2013, 2015-2020, 2022-2024)
- Volkswagen Beetle (2012-2019)
- Volkswagen Jetta City (2007-2009)
- Volkswagen Passat CC (2009-2010)
- Volkswagen Golf (2010-2021)
- Volkswagen CC (2009-2017)
- Volkswagen GTI (2006-2023)
- Volkswagen Tiguan (2009-2023)
- Volkswagen R32 (2008)
- Volkswagen Eos (2007-2016)
- Volkswagen Rabbit (2006-2009)
- Volkswagen Passat (2006-2010, 2012-2022)
- Audi A3 (2006-2020, 2022-2024)
- Volkswagen Jetta (2005-2024)
