RAYBESTOS 96209FZN Part Description
Manufacturer
Product Description
Raybestos Element3 Coated Brake Rotor
Application Summary
1999-1991 Toyota Tercel Front, 1999-1996 Toyota Paseo Front
Features & Benefits
- Grey Fusion 4.0® Coating
- Grey Fusion 4.0(R) Coating
- Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
- Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
- RPT® Rust Prevention Technology
- RPT(R) Rust Prevention Technology
- RPT® Rust Prevention Technology for long lasting rust prevention.
- RPT(R) Rust Prevention Technology for long lasting rust prevention.
- Cooling Vanes
- Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
- OE Matched
- OE Matched precision and performance.
- Non-Directional Finish
- A non-directional ground finish provides a product that is ready to install right out of the box.
RAYBESTOS 96209FZN Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.17 IN |
| Center Hole Diameter | 55.1 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.669 IN |
| Discard Thickness | 17 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Mounting Bolt Hole Circle Diameter | 100 MM |
| Mounting Bolt Hole Diameter | 0.56 IN |
| Mounting Bolt Hole Diameter | 14.2 MM |
| Mounting Bolt Hole Quantity | 4 |
| Nominal Thickness | 0.705 IN |
| Nominal Thickness | 17.9 MM |
| Outside Diameter | 9.37 IN |
| Outside Diameter | 238 MM |
| Overall Height | 1.685 IN |
| Overall Height | 42.8 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 4 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213228342 |
RAYBESTOS 96209FZN Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | 141711, YH141711, YH141711C, YH141711P |
| ALTROM IMPORTS | A03290 |
| AMERICAN REMANUFACTURED | 789-22073, 89-22073 |
| AUTOPART INTERNATIONAL | 78501 |
| AUTOSPECIALTY | JBR598, JBR598E |
| AUTOXTRA | 125174, AX3290 |
| AUTOZONE | 3290, 3290B, 3290DG, 3290DL, DL3290 |
| BECK/ARNLEY | 080-2387, 083-2387 |
| BENDIX | 141711 |
| BOSCH | 50011241, RBR3290 |
| BRAKE HEADQUARTERS | BR06235 |
| BRAKE PRO | 4612105 |
| BRAKEBEST | 50011241, 81-125174, 96209, 96209FZN, 96209R, 96209RGS, BD125174 |
| BREMBO | 09.5536.20, 25340 |
| Bridgestone | 7000917 |
| CALIFORNIA DRUM & ROTOR | 125174 |
| CENTRIC | 120.44075, 121.44075, 125.44075, 126.44075CSL, 126.44075CSR, 126.44075SL, 126.44075SR, 127.44075CL, 127.44075L, 127.44075R, 128.44075CL, 128.44075CR, 128.44075L, 128.44075R, 227.44075L, 227.44075R, 320.44075, 320.44075F |
| CENTURY | 9665 |
| CONTINENTAL-CONTITECH | CW18124 |
| Casting Numbers | 210531-C, 325101, 32901 |
| Centric Parts | 120.44075, 121.44075, 125.44075, 126.44075CSL, 126.44075CSR, 126.44075SL, 126.44075SR, 127.44075CL, 127.44075L, 127.44075R, 128.44075CL, 128.44075CR, 128.44075L, 128.44075R, 227.44075L, 227.44075R, 320.44075, 320.44075F |
| DURA CORP | BR3290 |
| DuraGo | BR3290 |
| EIS BRAKES | D17608 |
| EUROROTOR | TO663 |
| Eurorotor | TO-663 |
| GREN | 13802 |
| GUARDIAN | 52-125174 |
| ITM ENGINE COMPONENTS | 1601578 |
| MCI | 3854 |
| MIDAS | BR1759 |
| MIGHTY DISTRIBUTING SYSTEM | 3290 |
| MONROE BRAKES | BD125174 |
| NAPA BRAKES | TSR4417, TSR714 |
| NEWTEK AUTOMOTIVE | 3290 |
| Newtek Automotive USA | 3290 |
| PARTS MASTER | P125174 |
| PROMAX | 14-3290 |
| QUALIS | 3290 |
| QUALITEE INTERNATIONAL | 64-79-010 |
| QUALITY BRAND | 3290, Q278 |
| QUINTON HAZELL | BDC4415 |
| ROADMATES | 526674 |
| ROCKHILL | 3290 |
| STANDARD ROTORS AND DRUMS | 3290 |
| THE UNIVERSAL GROUP | 107900 |
| TOYOTA | 4351216070, 4351216120 |
| TRUSTAR | 479010, R79010 |
| TRW | DF4007S, DF4417S |
| UAP | 3290 |
| Ultra Brake | TO-663 |
| Universal | 107900 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X50624 |
| WAGNER BRAKE | BD125174, SB96209 |
| WINHERE | 442135, YH2135 |
RAYBESTOS 96209FZN Fits Vehicles
- Toyota Tercel (1991-1999)
- Toyota Paseo (1996-1999)
