(888) 312-8812 Login SignupDELPHI AF10350 Mass Air Flow Sensor
$14649
Limited availability at this price!
1 Day Lead Time
Get it by Monday, Feb 23
DELPHI AF10350 Part Description
Manufacturer
Product Description
Mass Air Flow Sensor
Features & Benefits
- Delphi mass air flow sensors are the global benchmark for accuracy and signal noise
- Delphi mass air flow sensors feature high quality sensing elements for outstanding performance over a wide range of ambient temperatures
- Delphi is a manufacturer of OE mass air flow sensors since their first use over 30 years ago
- All parts are calibrated and tested to match the OE part
- Probe solution offered wherever possible to reduce repair time by eliminating the need to replace the flow tube
- Delphi OE technology validated to match the vehicle applications
DELPHI AF10350 Specifications
Product Attributes
| Package Contents | Mass Air Flow Sensor - Probe Only |
| Item Grade | Premium |
| Color | Black and Silver |
| Housing Included | No |
| Terminal Type | Blade |
| Mounting Hardware Included | No |
| Universal Or Specific Fit | Specific |
| Grade Type | Standard Replacement |
| Connector Quantity | 1 |
| Connector Shape | Rectangle |
| Mounting Hole Quantity | 2 |
| Terminal Quantity | 4 |
| Connector Gender | Female |
| Terminal Gender | Male |
| Wiring Harness Included | No |
| Mounting Type | Bolt-On |
| Mounting Bracket Included | No |
| Sensor Casing Length | 92 MM |
| Sensor Casing Width | 50.5 MM |
| Voltage | 12.0 2H |
| Gasket Or Seal Included | Yes |
| Bolt Hole Center To Bolt Hole Center | 68.70 MM |
| Mounting Hole Diameter | 0.1 IN |
| Seal Outside Diameter | 16 mm |
| Seal Quantity | 1 |
| Sensor Casing Length | 3.6 IN |
| Sensor Casing Width | 1.9 IN |
| Bolt Hole Center To Bolt Hole Center | 2.70 IN |
| Mounting Hole Diameter | 4.5 MM |
| Seal Outside Diameter | 0.6 IN |
| Intake Air Temperature (IAT) Included | No |
Additional Information
| Harmonized Tariff Code (HTS) | 9026802000 |
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9026800000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| UPC | 00689604268094 |
| VMRS Code | 045021019 |
| UNSPSC | 41111931 |
DELPHI AF10350 Cross References
| Brand | Part Number |
|---|---|
| BWD | 29038, MA1011 |
| CARDONE New | 86-9539 |
| CARDONE Reman | 74-9539 |
| Dorman | 917-842 |
| Ford | F6SZ 12B579-AARM |
| GLOBAL PARTS DISTRIBUTORS | 1813165 |
| Hitachi Automotive | AFH70-02CM, MAF0016 |
| Motorcraft | AFLS-121RM |
| N/A | DL-3076, 245-1026, 245-2026 |
| NAPA Reman Computers | MAF69539, XTP49539 |
| Richporter | MA165 |
| STANDARD IGNITION | MAS0127 |
| Spectra Premium | MA165, MA228 |
| Standard Motor Products | MAS0127, MF0886 |
DELPHI AF10350 Fits Vehicles
- Mercury Cougar (1996-1997)
- Ford Thunderbird (1996-1997)
