RAYBESTOS 96783FZN Part Description
Manufacturer
Product Description
Raybestos Element3 Coated Brake Rotor
Application Summary
2003-1998 Mercedes-Benz ML320 Front, 2005-2003 Mercedes-Benz ML350 Front, 1999 Mercedes-Benz ML430 Front
Features & Benefits
- Grey Fusion 4.0® Coating
- Grey Fusion 4.0(R) Coating
- Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
- Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
- RPT® Rust Prevention Technology
- RPT(R) Rust Prevention Technology
- RPT® Rust Prevention Technology for long lasting rust prevention.
- RPT(R) Rust Prevention Technology for long lasting rust prevention.
- Cooling Vanes
- Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
- OE Matched
- OE Matched precision and performance.
- Non-Directional Finish
- A non-directional ground finish provides a product that is ready to install right out of the box.
RAYBESTOS 96783FZN Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.638 IN |
| Center Hole Diameter | 67 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.906 IN |
| Discard Thickness | 23 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Mounting Bolt Hole Circle Diameter | 112 MM |
| Mounting Bolt Hole Diameter | 4.409 IN |
| Mounting Bolt Hole Diameter | 112 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.02 IN |
| Nominal Thickness | 25.9 MM |
| Outside Diameter | 11.921 IN |
| Outside Diameter | 302.8 MM |
| Overall Height | 2.018 IN |
| Overall Height | 51.25 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213145472 |
RAYBESTOS 96783FZN Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH145201, YH145201C |
| ALTROM IMPORTS | 1634210212 |
| AMERICAN REMANUFACTURED | 89-74036 |
| AUTOSPECIALTY | EBR626, EBR626E |
| AUTOXTRA | AX125698 |
| AUTOZONE | 34147, 34147DG |
| BECK/ARNLEY | 083-2783 |
| BENDIX | 145201 |
| BRAKEBEST | 36010930, 96783RGS, 96783, 96783FZN, 96783R, BD126238 |
| BREMBO | 09.7606.11, 09.7823.10, 25530 |
| Brembo | 09.7823.11 |
| CENTRIC | 120.35036, 121.35036, 125.35036, 125.35036CRY, 126.35036CSL, 126.35036CSR, 126.35036SL, 126.35036SR, 127.35036L, 127.35036R, 128.35036L, 128.35036R, 320.35036H, 320.35036 |
| CONTINENTAL-CONTITECH | CW26116 |
| Casting Numbers | 210737-C, 325905 |
| Centric Parts | 120.35036, 121.35036, 125.35036, 125.35036CRY, 126.35036CSL, 126.35036CSR, 126.35036SL, 126.35036SR, 127.35036L, 127.35036R, 128.35036L, 128.35036R, 320.35036, 320.35036H |
| DELPHI | RB318 |
| DURA CORP | BR34147, BR3414702 |
| DuraGo | BR34147 |
| EUROROTOR | ME194 |
| MERCEDES-BENZ | 1634210012, 1634210212 |
| MIGHTY DISTRIBUTING SYSTEM | 34147 |
| NEWTEK AUTOMOTIVE | 34147 |
| Newtek Automotive USA | 34147 |
| PAGID | 355105832 |
| PAGID Racing | 355105832 |
| POWERSTOP | EBR626EVC |
| PROMAX | 14-34147 |
| QUALIS | 34147 |
| QUALITY BRAND | Q163 |
| QUINTON HAZELL | BDC4817 |
| STANDARD ROTORS AND DRUMS | 34147 |
| TRW | 4150 |
| UAP | 34147 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51370 |
| WABCO | PS126238 |
| WABCO - Archived | PS126238 |
| WAGNER BRAKE | BD126238 |
| WINHERE | 662712, YH2712 |
| WORLDPAC | 1407-78949 |
RAYBESTOS 96783FZN Fits Vehicles
- Mercedes-Benz ML350 (2003-2005)
- Mercedes-Benz ML430 (1998-1999)
- Mercedes-Benz ML320 (1998-2003)
