RAYBESTOS 96760FZN Raybestos Element3 Coated Brake Rotor

★★★★★ (0)
96760FZN by RAYBESTOS - Raybestos Element3 Coated Brake Rotor
RAYBESTOS

$55.49

Limited availability at this price!

1 Day Lead Time

Get it by Tuesday, Jun 30
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
This item will ship about 1 day after the date of purchase.

RAYBESTOS 96760FZN Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Element3 Coated Brake Rotor

Application Summary

2010-2002 Lexus SC430 Rear, 2005-1998 Lexus GS300 Rear, 2005-2001 Lexus IS300 Rear, 2000-1998 Lexus GS400 Rear, 2005-2001 Lexus GS430 Rear

Features & Benefits

  • Grey Fusion 4.0® Coating
  • Grey Fusion 4.0(R) Coating
  • Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
  • Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
  • RPT® Rust Prevention Technology
  • RPT(R) Rust Prevention Technology
  • RPT® Rust Prevention Technology for long lasting rust prevention.
  • RPT(R) Rust Prevention Technology for long lasting rust prevention.
  • Cooling Vanes
  • Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
  • OE Matched
  • OE Matched precision and performance.
  • Non-Directional Finish
  • A non-directional ground finish provides a product that is ready to install right out of the box.

RAYBESTOS 96760FZN Specifications

Product Attributes

ABS Tone Ring Included No
Center Hole Diameter 2.442 IN
Center Hole Diameter 62.05 MM
Conventional Or Drum-In-Hat Type Rotor Drum-In-Hat
Discard Thickness 0.413 IN
Discard Thickness 10.5 MM
Harmonize Code 8708.30.5030
Mounting Bolt Hole Circle Diameter 4.5 IN
Mounting Bolt Hole Circle Diameter 114.3 MM
Mounting Bolt Hole Diameter 4.5 IN
Mounting Bolt Hole Diameter 114.3 MM
Mounting Bolt Hole Quantity 5
Nominal Thickness 0.472 IN
Nominal Thickness 12 MM
Outside Diameter 12.08 IN
Outside Diameter 306.85 MM
Overall Height 2.505 IN
Overall Height 63.65 MM
Salability Restrictions No
Solid Or Vented Type Rotor Vented
Stud/Lug Hole Quantity 5
UNSPSC Code 25171715

Additional Information

Country of Origin (Primary) CN
Canadian Harmonizing Tariff Code 8708309990
Harmonized Tariff Code (HTS) 8708305030
UPC 00887213145427

RAYBESTOS 96760FZN Cross References

BrandPart Number
ADVANCE AUTO PARTS145200, YH145200, YH145200C
ADVICSA6R033U
AMERICAN REMANUFACTURED89-22109
AUTOSPECIALTYJBR739, JBR739E
AUTOXTRA125641, AX31253
AUTOZONE31253, 31253DG
BECK/ARNLEY083-2790
BENDIX145200
BOSCH50011250
BRAKEBEST50011256, 96760, 96760FZN, 96760R, 96760RGS, BD125641
BREMBO08.8808.85, 25583
Brembo08.A038.11
CALIFORNIA DRUM & ROTOR31253
CENTRIC120.44090, 120.44090CRY, 121.44090, 125.44090, 125.44090CRY, 126.44090CSL, 126.44090CSR, 126.44090SL, 126.44090SR, 127.44090CL, 127.44090CR, 127.44090L, 127.44090R, 128.44090CL, 128.44090CR, 128.44090L, 128.44090R, 227.44090L, 227.44090R, 320.44090, 321.44090
CONTINENTAL-CONTITECHCW12703
Casting Numbers211198-C, 325479
Centric Parts120.44090, 120.44090CRY, 121.44090, 125.44090, 125.44090CRY, 126.44090CSL, 126.44090CSR, 126.44090SL, 126.44090SR, 127.44090CL, 127.44090CR, 127.44090L, 127.44090R, 128.44090CL, 128.44090CR, 128.44090L, 128.44090R, 227.44090L, 227.44090R, 320.44090, 321.44090
DURA CORPBR31253, BR3125302
DuraGoBR31253
EUROROTORTO6114
MIGHTY DISTRIBUTING SYSTEM31253
NAPA BRAKESSDK6350, TSR475
NEWTEK AUTOMOTIVE31253
Newtek Automotive USA31253
PEP BOYS31253G
POWERSTOPJBR739EVC
PROMAX14-31253
QUALIS31253
QUALITY BRANDQ046
QUINTON HAZELLBDC5142
STANDARD ROTORS AND DRUMS31253
THE UNIVERSAL GROUP128227
TOYOTA4243130260, 4243153011
TRW4509, DF2646S
TopNotchTN96760GEO
UAP31253
Universal128227
VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURINGX51272
WABCOPS125641
WABCO - ArchivedPS125641
WAGNER BRAKEBD125641, BD125641E
WINHERE661349, YH1349
WORLDPAC1407-79771, 1427-719984

RAYBESTOS 96760FZN Fits Vehicles

  • Lexus SC430 (2002-2010)
  • Lexus IS300 (2001-2005)
  • Lexus GS430 (2001-2005)
  • Lexus GS400 (1998-2000)
  • Lexus GS300 (1998-2005)
