(888) 312-8812 Login SignupDELPHI AF10335 Mass Air Flow Sensor
MSRP: $192.48
$17799
Save $14.49
Limited availability at this price!
In Stock
Get it by Wednesday, Dec 17
DELPHI AF10335 Part Description
DELPHI AF10335 Specifications
Product Attributes
| Package Contents | Mass Air Flow Sensor - Complete Assembly |
| Item Grade | Premium |
| Color | Black and Silver |
| Housing Included | Yes |
| Inlet Connection Diameter | 2.748 IN |
| Inlet Connection Diameter | 69.8 MM |
| Outlet Connection Diameter | 2.7 IN |
| Outlet Connection Diameter | 69.8 MM |
| Terminal Type | Blade |
| Mounting Hardware Included | No |
| Universal Or Specific Fit | Specific |
| Grade Type | Regular |
| Connector Quantity | 1 |
| Connector Shape | Rectangle |
| Mounting Hole Quantity | 2 |
| Housing Material | Aluminum, Plastic |
| Terminal Quantity | 6 |
| Connector Gender | Female |
| Terminal Gender | Male |
| Wiring Harness Included | No |
| Mounting Type | Bolt-On |
| Mounting Bracket Included | No |
| Sensor Casing Length | 128.7 MM |
| Sensor Casing Width | 91 MM |
| Voltage | 12.0 2H |
| Gasket Or Seal Included | No |
| Bolt Hole Center To Bolt Hole Center | 49.00 MM |
| Mounting Hole Diameter | 6 MM |
| Seal Quantity | 0 |
| Sensor Casing Length | 5.0 IN |
| Sensor Casing Width | 3.5 IN |
| Bolt Hole Center To Bolt Hole Center | 1.90 IN |
| Mounting Hole Diameter | 0.2 IN |
Additional Information
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9026800000 |
| Harmonized Tariff Code (HTS) | 9026802000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| UPC | 00689604244272 |
| VMRS Code | 045021019 |
| UNSPSC | 41111931 |
DELPHI AF10335 Part Interchanges
| Brand | Part Number |
|---|---|
| Bosch | 0986280102 |
| Spectra Premium | MA118 |
| ACDelco | 213-3336 |
| Richporter | MA118 |
| BWD | 29085 |
| Volvo | 1346645, 1346645-0 |
| CARDONE Reman | 74-10005 |
| NAPA Reman Computers | XTP410005 |
| WAI | MAF20187T |
| N/A | MQ7322, DL-6040, 245-1098, MF9651 |
DELPHI AF10335 Fits Vehicles
- Volvo 780 (1989)
- Volvo 745 (1985)
- Volvo 760 (1985-1989)
- Volvo 740 (1985-1988)
- Volvo 245 (1985-1988)
- Volvo 244 (1985-1988)
