WEATHERHEAD part description

Abrasion Resistance Premium
Application Hydraulic system with Petroleum based fluids for low temperature application
Burst Pressure 21610 psi
Certification(s) SAE 100R15
Color Black
Compliances MSHA Approved
Conductivity Conductive
Construction 6 Spiral
Cover Material Synthetic Rubber
Dash Size -32
Description Product Name Eaton EC810 Series Hose
Description Short SCHLAUCH 4SP EIS SCHLAUCH
ECCN EAR99
Impulse Cycle Life 500000 cycle
Inside Diameter 2 inch
Lay Line Style Ink Transfer
Maximum Working Temperature 212 degree Fahrenheit
Minimum Bend Radius 24.8 inch
Minimum Working Temperature -70 degree Fahrenheit
Outside Diameter 2.86 inch
Product Trade Name EC810 Series
Qualified Hose Fittings 4S, 6S
Reinforcement Material Wire
Sub Brand Eaton
Tube Material Synthetic Rubber
Tube Wall Thickness 0.41 inch
UNSPSC 40142020
Working Pressure 6100 psi

Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
