CSF part description

Product Description

Radiator

Features & Benefits

  • OEM specified Copper-Brass Construction
  • Easy to recore & repair
  • No risk for coolant contamination and damage to sensitive seals, water pump & thermostat
  • OEM specified "Single Piece - Deep Drawn" Brass Tanks with Ribs for added Strength & Durability
  • Tubes - Special coated OEM specified "Double Lock Seam Joints" for Long Life
  • Fins (Heart of Radiator) - High Performance "Multi-Louvered Design" - OEM Spec
  • Side Channels - Coated Steel for Strength & Durability
  • Reinforced Inlet & Outlet Connections with "Thru Pipe Design"
  • 100% leak tested before leaving factory at 150% of operating pressure
  • Industry Best Packaging - "10 Foot Drop Test" Standard
  • Drop-in Fit
  • Built for OEM Cooling - High Performance Transmission Cooler with special Built-in Turbulators
  • All components are installed, torqued & tested on Radiator during assembly

Product Attributes

Tech Note Rugged ALL METAL Heavy Duty, Multifit model; Supplied with snap-on & push-on oil cooler fittings; Removable bracket for applications with A/C.
Hazardous Material No
Csf Cap Number 4501
Radiator Cap Supplied No
Down Flow Or Cross Flow Type Down Flow
Tank Material Brass
Core Material Copper
Oil Cooler (in) 12 (high-effeciency Concentric Type)
No. Of Rows 3
Outlet Diameter 1 1/2 Left IN
Inlet Diameter 1 1/4 Right IN
Outlet Width (in) 2
Outlet Length (In) 20 1/16
Inlet Width (in) 2 1/16
Inlet Length (In) 20 1/16
Core Thickness 1 11/16 IN
Core Width 20 IN
Core Length (in) 18 1/8 IN
Box Weight (lbs) 20
Box Height (in) 5 11/16
Box Width (in) 25 5/16
Box Length (in) 28 1/16

Part Interchanges

Fits Vehicles

  • Jeep Wrangler (1987-1995, 1997-2004)

When it comes to heavy-duty or performance vehicle cooling, trust only the experts—CSF. Called "The Cooling Experts," CSF has sold over 30 million products, including intercoolers, condensers, radiators, pressure caps, racing radiators, and other solutions to vehicle cooling problems. Whatever the application, CSF has the ideal solution. Its portfolio comprises over 3000 models manufactured in state-of-the-art, ISO-certified facilities. Every CSF product, especially its radiators, has been rigorously tested—Hydrostatic, vacuum decaying, life-cycle testing—and is meticulously crafted to provide a "drop-in fit." This world leader in automotive cooling now exclusively sells its products through its huge network of over 500 distributors across the country.
