ACCURIDE part description

Technical Specifications

Aftermarket Status Active
Finished Weight 79
Special Information TruPilot brake drum, has 8.78 & 8.66 pilot diameters. Version of 3726X.
Maximum Wear Diameter 15.12
Drum Mount Outboard
Drum Type BEA
Wheel Type Disc
Overall Diameter 17.32
Dust Shield Recess Diameter 16
Dust Shield Recess Depth 0.8
Brake Size 15.00x4.00
Brake Surface Diameter 15
Brake Surface Width 4.66
Mounting Flange Diameter 13.38
Overall Depth 9.18
Pilot Diameter 8.78
Bolt Circle Diameter 11.25
Number of Bolt Holes 10
Bolt Hole Size 1.25
Squealer Band Width 1.58
Mounting Flange Thickness 0.5
Outside Sidewall Diameter 16.01
Sidewall Offset 4.3
Inside Finished Diameter 13.2
Brake Size 4
Bolt Circle Diameter (In.) 15
Bolt Holes And Size 10.00
Overall Depth (In.) 9.18
Brake Type BEA

Accuride® is a proud manufacturer of durable and dependable wheels for commercial and passenger vehicles. It is committed to delivering only the highest quality products to OEMs and the aftermarket, with the Accuride Quality and Lean Manufacturing System (QLMS) in place at each of its ISO/IATF 16949SO-certified facilities. Although this brand is more popular for its aluminum and steel commercial vehicle wheels, it also offers some of the best brake drums, brake rotors, slack adjusters, and hub assemblies in the market today. All these components are designed and produced following the strictest standards for maximum performance, durability, and reliability.
