RAYBESTOS 981063 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2020-2015 Acura TLX Front, 2016-2014 Acura MDX Front
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 981063 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.52 IN |
| Center Hole Diameter | 64 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.024 IN |
| Discard Thickness | 26 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 8.287 IN |
| Inside Diameter | 210.5 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.496 IN |
| Mounting Bolt Hole Circle Diameter | 114.2 MM |
| Mounting Bolt Hole Diameter | 0.496 IN |
| Mounting Bolt Hole Diameter | 12.6 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.102 IN |
| Nominal Thickness | 28 MM |
| Outside Diameter | 12.598 IN |
| Outside Diameter | 320 MM |
| Overall Height | 1.858 IN |
| Overall Height | 47.2 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213157550 |
RAYBESTOS 981063 Cross References
| Brand | Part Number |
|---|---|
| AUTOXTRA | AX901318 |
| AUTOZONE | 74017 |
| AutoZone | 74017DL |
| BRAKEBEST | 981063, 981063FZN, 981063R |
| BrakeBest | 921673RGS |
| CENTRIC | 120.40090, 120.40090CRY, 121.40090, 126.40090SL, 126.40090SR, 127.40090L, 127.40090R, 128.40090L, 128.40090R, 227.40090L, 227.40090R, 320.40090, 120.4009, 121.40087 |
| Centric Parts | 120.40090, 120.40090CRY, 121.40090, 126.40090SL, 126.40090SR, 127.40090L, 127.40090R, 128.40090L, 128.40090R, 227.40090L, 227.40090R, 320.40090 |
| DURA CORP | BR901318 |
| DuraGo | BR901318 |
| Dynamic Friction Company | 600-58026, 604-58026 |
| HONDA | 45251TZ3A00, 45251TZ5A00, 45251TZ5A01 |
| MAGMA PRODUCTS | PSR265110 |
| NEWTEK AUTOMOTIVE | R1318 |
| Newtek Automotive USA | R1318 |
| POWERSTOP | JBR1589EVC |
| PROMAX | 14-610010 |
| Qualis | 45699 |
| TopNotch | TN981063GEO |
| UAP | 2901318 |
| WORLDPAC | 1407-503882, 1427-731840 |
| Wagner Brake | BD180697E |
| Winhere | 6621673 |
RAYBESTOS 981063 Fits Vehicles
- Acura TLX (2015-2020)
- Acura MDX (2014-2016)
