(888) 312-8812 Login SignupRAYBESTOS 781768 Raybestos Specialty - Street Performance Brake Rotor
$23499
Limited availability at this price!
In Stock
Get it by Thursday, Sep 3
RAYBESTOS 781768 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2021-2014 Jeep Cherokee Front, 2017-2015 Chrysler 200 Front
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 781768 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.76 IN |
| Center Hole Diameter | 70.1 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.039 IN |
| Discard Thickness | 26.4 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 7.799 IN |
| Inside Diameter | 198.1 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.331 IN |
| Mounting Bolt Hole Circle Diameter | 110 MM |
| Mounting Bolt Hole Diameter | 0.618 IN |
| Mounting Bolt Hole Diameter | 15.7 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.102 IN |
| Nominal Thickness | 28 MM |
| Outside Diameter | 12.992 IN |
| Outside Diameter | 330 MM |
| Overall Height | 1.559 IN |
| Overall Height | 39.6 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213137040 |
RAYBESTOS 781768 Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH524198, YH524198C, YH524198P |
| ATE BRAKE PRODUCTS | 428191 |
| AUTOPARTSOURCE | 491376 |
| AUTOXTRA | AX901270 |
| AUTOZONE | 72122, 72122DG, 72122DL |
| Alfa Romeo | 68618730AA |
| Autoxtra | AX901270P |
| BOSCH | 16011530 |
| BRAKEBEST | 16011530, 721622RGS, 781768, 781768FZN, 781768R |
| Brembo | 09.N268.11 |
| CENTRIC | 120.58014, 120.58014CRY, 121.58014, 126.58014CSL, 126.58014CSR, 126.58014SL, 126.58014SR, 127.58014L, 127.58014R, 128.58014L, 128.58014R, 320.58014 |
| CHRYSLER | 04779884AA, 4779884AA, 4779884AB, 4779884AC, 68242650AA, 68242650AB |
| Centric Parts | 120.58014, 120.58014CRY, 121.58014, 126.58014CSL, 126.58014CSR, 126.58014SL, 126.58014SR, 127.58014L, 127.58014R, 128.58014L, 128.58014R, 320.58014 |
| Chrysler | 68618730AA, 68506590AA |
| DURA CORP | BR901270 |
| DuraGo | BR901270, BR90127002, BR901270-02, BR901970, BR901970-01, BR901992 |
| Dynamic Friction Company | 600-42013 |
| Jeep | 68506590AA |
| MAGMA PRODUCTS | PSR145203 |
| NEWTEK AUTOMOTIVE | R1270 |
| Newtek Automotive USA | R1270 |
| POWERSTOP | AR83087EVC |
| PROMAX | 14-630004 |
| Parts Master | 901270 |
| Qualis | 43197 |
| TopNotch | TN781768GEO |
| UAP | 2901270 |
| Ultra Brake | 51301 |
| WAGNER BRAKE | BD180650E |
| WORLDPAC | 1407-524198, 1427-731814 |
| Wagner Brake | BD180650 |
| Winhere | 6621622 |
RAYBESTOS 781768 Fits Vehicles
- Alfa Romeo Tonale (2025)
- Jeep Compass (2023, 2025)
- Dodge Hornet (2023-2025)
- Chrysler 200 (2015-2017)
- Jeep Cherokee (2014-2023)
