FLEXFAB part description

4" SILICONE
9.5" LEGS
CAC OR COOLNT HSE

Product Description

7884-400 BLUE 90° SILICONE ELBOWS, 4 ID, 12 IN

Features & Benefits

  • Extreme Temperature Resistance;Extreme Duty Cycle Tested for Hostile Engine Environments;Low Dilation Design ;Prevents Expansion;Engineered for Coolant and Charge Air Connector Systems

Associated Clamp 2582-0064 or 2584-0462 (not included)

Product Attributes

Inside Diameter 4 IN
Inside Diameter 102 MM
Outside Diameter 4.32 IN
Outside Diameter 110 MM
Leg Length - Avail. Associated Clamp (not included)ing Space 9.5 IN
Bend Radius (Inch) 6 IN
Burst Pressure - SAE J20 R1 50 PPI
Burst Pressure - TMC 100 PPI
Weight (LB) 1.5 LBS
Associated Clamp (not included) 2582-0064 or 2584-0462

Additional Information

Country of Origin (Primary) US
Warranty Special See Rep
VMRS Code 053008012

FLEXFAB 7884-400 Cross Reference

We have 2 alternatives for the 7884-400 by FLEXFAB:

Flexfab® delivers high-quality engineering that can be trusted by even the most discerning vehicle and truck owners, mechanics, and fleet managers around the world. This world-renowned manufacturer of high-grade silicone hoses, ducting, and tubing takes pride in its patented manufacturing process. Flexfab’s exclusive calendaring, compounding, molding and extruding processes as well as bonding organic rubber, silicone rubber, and reinforcing materials are what makes its products best in class. Established by Douglas C. DeCamp and Bill Pierce in 1961, Flexfab started out as a small business in an abandoned 7,000-square-foot store in Hasting, Michigan. The company’s culture of excellence makes it a world-class supplier of high-temperature silicone hose, custom-designed parts, and other high-quality products to some of the world’s largest companies across the globe.
