MONROE 5502 Part Description
Manufacturer
Product Description
OESpectrum Suspension Shock Absorber
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
MONROE 5502 Specifications
Product Attributes
| Lower Mount Code | LS33 |
| Upper Mount Code | S5 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 13.33 IN |
| Extended Length | 21.87 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 2.5/16" Sleeve OAL |
| Parts Pack(s) | P01637 |
| Travel Length | 6.25 in |
| Upper Mount Type | Stem Mount - 2.5/8" Stem Length X 1/2"-13 Thread Pitch |
| Compressed Length | 338.6 MM |
| Extended Length | 555.5 MM |
| Travel Length | 158.8 MM |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS33 |
| Upper Mount Code | S5 |
| Mounting Hardware Included | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01168 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598164490 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 5502 Cross References
| Brand | Part Number |
|---|---|
| FCS | 346112 |
| FCS AUTO PARTS | 346112 |
| KYB | 349218 |
| KYB AMERICA LLC. | 349218 |
| MasterPro Shocks and Struts | TY117 |
| Monroe Shocks & Struts | 210000 |
| NAPA Shocks | 5502, NS5502 |
| OEM | 4853080731, 4853080595, 4853080600 |
| PRT | 373364 |
| SENSEN | 1213-0593 |
| Sensen | 12130593 |
| Top Quality | 785502 |
| Toyota | 4851080626, 4851080663, 4851080755, 4851080836, 4852080335, 4852080364, 4852080432, 4852080510, 4853080595, 4853080600, 4853080690, 4853080731 |
MONROE 5502 Fits Vehicles
- Toyota Prius V (2012-2017)
