(888) 312-8812 Login SignupBENDIX 065478 Air Dryer
Tap to view 5 more
MSRP: $1,313.79
$1,18349
Save $130.30
Limited availability at this price!
In Stock
Get as soon as Tuesday, Oct 27
BENDIX 065478 Part Description
Manufacturer
Product Description
Air Dryer
Features & Benefits
- Moisture removal keeps lines and valves from freezing in winter
- Works with the governor to purge collected water from the system
- Answers recurring winter line freeze-ups caused by moisture
- Tank draining after the swap clears water left in the system
Bendix Air Brake Dryer
Trucks working in cold climates, where moisture in the air lines can freeze, are where the Bendix Air Brake Dryer earns its place in the air system. The dryer removes water vapor from compressed air before it reaches the tanks, so less moisture is left to freeze in valves and lines. Fitting it as a complete unit replaces worn internal valves and seals along with the drying stage. Draining the tanks after the Bendix 065478 goes in removes water the old dryer let through.
BENDIX 065478 Specifications
Product Attributes
| Air Dryer Type | Stand-Alone |
| Body Mounting | A~ .425 Hole with 3/8-24 UNF-2A Bolted Joint (8x) |
| Cartridge Stabilizer Ring Included | No |
| Cartridge Thread | 5/8-11 UNC-2A |
| Cartridge Type | Standard |
| Clamp Band Angle (CW from SUP) | Not applicable to this part |
| Clearance to Remove Cartridge | 11.00 IN |
| Control Port | 1/4-18 NPT |
| Cut-In Pressure | Not applicable to this part |
| Cut-Out Pressure | Not applicable to this part |
| Delivery Port 1 | 1/2-14 NPT |
| Delivery Port 2 | Not applicable to this part |
| Extended Purge Port | Not applicable to this part |
| Governor Included | No |
| Governor Mounting Bracket | Not applicable to this part |
| Governor Mounting Bracket Angle (CCW from SUP) | Not applicable to this part |
| Governor Type | Not applicable to this part |
| Heater / Thermostat Rating | 12V / 75W |
| Heater Connector Color | White |
| Heater Connector Type | Metri-Pack 280 Series 2-Way Sealed Connector (Male) |
| Lower Mounting Bracket | .41 IN x 1.15 IN Slot (2x) |
| Lower Mounting Bracket Angle (CCW from SUP) | Loose in Box |
| Market Indicator | Aftermarket New |
| Maximum Inlet Temperature | 160 AdegF (71 AdegC) |
| Minimum Operating Temperature | -40 AdegF (-40 AdegC) |
| Purge Exhaust Port | Standard |
| Purge Valve Type | Hard Seat |
| Purge Volume | Standard |
| Remote Fill Feature | Not applicable to this part |
| Remote Purge Port | Not applicable to this part |
| Safety Valve Opening Pressure | 200 PSI |
| Supply Port | 1/2-14 NPT |
| Turbo Cut-off Function | Not applicable to this part |
| Upper Mounting Bracket | .41 IN x 1.15 IN Slot (2x) |
| Upper Mounting Bracket Angle (CCW from SUP) | Loose in Box |
| Upper Mounting Bracket Height (from Lower Mounting Bracket) | Loose in Box |
| Upper Mounting Type | Strap (Carbon Steel) |
Additional Information
| Country of Origin (Primary) | MX |
| UPC | 04068078353561 |
| VMRS Code | 013010252 |
BENDIX 065478 Cross References
| Brand | Part Number |
|---|---|
| BW065478 | |
| N/A | 107695 |
